high capacity rotary peeling lathe
- 1 Set / Sets per Month
- QINGDAO
Product Details
Condition: | New | Type: | Other, rotary lathe | Place of Origin: | Shandong, China |
Brand Name: | HAIYONG | Model Number: | BXQ1822 | Voltage: | 380V |
Power(W): | 21750 | Dimension(L*W*H): | 3700X1800X1490 | Weight: | 5500kg |
Certification: | ISO9001 | Warranty: | i year | After-sales Service Provided: | Overseas service center available |
Product Description
rotary peeling lathe
basic information of the rotary peeling lathe
1 the max cutting length is 1350,2000,2600mm. the longer one need to special making.
2 the standard cutting diameter is 300mm. the bigger one we can produce as your requirement.
3 the standard veneer thickness is 0.8 to 3mm. the special thickness need to inform in advance.we also can produce.
4 the final veneer log is 26mm.
5 the machine can cut all kind of wood, soft and hard.
6 the machine body is heavy and treated by heat treatment.
7the accurrcy of the machine is 0.1mm.
8 we have the fast speed model , max produce speed is 60m/min.
technical specifications of rotary peeling lathe
Model | BHX1815 | BHX1822 | BHX1827 |
Max cutting length (mm) | 1350 | 2000 | 2600 |
Max cutting diameter (mm) | Φ300 | Φ300 | Φ300 |
Log-core diameter (mm) | Φ26 | Φ26 | Φ26 |
Cutting thickness (mm) | 0.8-3.0 | 0.8-3.0 | 0.8-3.0 |
Veneer output speed (m/min) | 42 | 42 | 42 |
Power (kw) | 19.75 | 21.75 | 25.75 |
Overall dimension (mm) | 3320*1800*1260 | 3700*1800*1490 | 4585*1800*1560 |
N.W (kg) | 3500 | 5500 | 7000 |
