Specifications
N330, N660, N774 Carbon Black Refining Machine for Pyrolysis Carbon BlackPLC control
no pollution
unique technology speciall
N330, N660, N774 Carbon Black Refining Machine for Pyrolysis Carbon Black
Introduction:
It is the first complete set of machine in China that can process recycled carbon black to ultrafine carbon black with mature technology.
It turns the waste tyre carbon black after pyrolysis to Semi-reinforcing carbon black, N330, N660 and N774, with the market price about 1000USD/ton.
The ultrafine carbon black from the machine is called “formula carbon black”. Therefore, it can blend to any kind of carbon black according to the requirement of the clients and the raw material itself.
Technical Specification:
No | Item | Project | ||
1 | Model |
| XY-850 carbon black processing production line | |
2 |
| Feeding Mode |
| Downstream Feeding |
3 |
| Availability of Raw Materials |
| Carbon Black Pyrolysis |
4 |
| Structure |
| Vertical multi-Level Mill |
5 |
| Main Part Material |
| Chromium-manganese alloy |
6 |
| Main Part Size& Daily Capacity |
| 24m * 9m * 8m, 1MT/H |
7 |
| Powder Collection Mode |
| Double row cyclone powder collection device |
8 | Ash Processing |
| Pulse Classic processor | |
9 |
| Carbon Black Yield |
| 90%-98% |
10 |
| Wind Power |
| Wind Power |
11 | Main Part Speed |
| 1800 | |
12 |
| Powder Choosing Speed |
| 200-2980 |
13 |
| Total Power |
| 175kw/h |
14 |
| dust Elimination Mode |
| Pulse Inner Loop |
15 |
| Iron Elimination Mode |
| Model 650 magnetic separator |
16 |
| Granulation Method |
| Dry / wet granulator |
17 |
| Deliver Time |
| about 45Days |
18 |
| Installation Mode |
| With foundation |
19 |
| Installation Area |
| (W*L*H) |
20 |
| Installation and Testing Period |
| ≤30days Per set |
21 |
| Noice |
| ≤85 |
22 |
| Operating Mode |
| continuous |
23 |
| Equipment Maintenance |
| 2 weeks a time |
24 |
| Manpower |
| 2 |
25 |
| Total weight(MT) |
| About 15 |
26 |
| Container Number |
| With 3*40HQ containers |
The 3D Photo
Packaging & Shipping
Packaging Detail: | 40"FR&40"HQ,All goods are packed with exported standards packaged to sure no damaged during transportation. |
Delivery Detail: | about 20 days after receiving deposit |
TESTING REPORT:
About Us
Shangqiu JinYuan Machinery Equipment Co.LTD.,is the first domestic professional institute in the recycling and utilization
of solid wastes (waste plastic,waste tyre,rubber).
Our company has developed XY-Series environmental protection equipments.Up to now, our products include Pyrolysis
Plants for waste rubber,plastic and tyres,normal or negative pressure. Distillation Plants for waste engine oil, pyrolysis
fuel oil,crude oil and the Carbon Black Deep-process Machines.
We has owned 14 national patents .Our comany also has achieved CE,SGS,ISO,BV,BUV certificates.The emission can
meet GB13271---2001 related standards.
Service:
l We have professional service staff who is responsible for your running plant besides our sales manger and
the technicians.
l 30 Engineers available to go overseas with the installation and the service.
l Within 12 hours response to you , within24 hours a solution for you
l Quality warranty period: One year warranty for the main reactor of pyrolysis machines and lifetime
maintenance for complete set of machines.
