rubber laser cutting machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Qingdao

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Rubber Cutting Machine		Place of Origin	Shandong, China
Brand Name	JQ		Model Number	JQ-1312

Packaging Details

Package:
Our laser machines are packed with plywood, We will package the machine with preservative film firstly, and next package the machine with plywood,then we will fill foam in the space between the machine and the plywood. At last, we will enlace the wooden case with iron belts.

Product Description

Specifications

rubber laser cutting machine:
1)used for rubber, cloth, leather, acrylic, die board cutting
2)ball screw transmission
3)CE

JQ-1312 Laser Cutter With Ballscrews

Performance Features:

1. Configure high power laser tube.

2. DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.

3. Owns functions of restoring from power off, continuation on break point.

4. Transmit files directly in Coreldraw, AutoCAD,etc.

5. Adopt international linear rail, more precision.

Model	JQ-1312 rubber laser cutting machine
Laser Power	150W
Laser Type	CO2 sealed, glass laser tube, water cooling
Work Area	1300 X 1200 mm
Cooling Type	Water-cooled and Protection System
Engraving Scanning Speed	0-60000 mm/min
Cutting Speed	0-15000mm/min
Laser Output Control	1-100% Software Setting
Smallest Character Engraving	English: 1.0X1.0 mm
Highest Scanning Precision	2500DPI
Power Supply	AC 110-220V±10%, 50-60Hz
Operating Temperature	0°-45°C
Operating Humidity	5%-95%
Locating Precision	≤±0.01mm
Supported File Format	DSTPLTBMPDXFAI
Compatible Software	TAJIMACORELDRAWPHOTOSHOPAUTOCADAll Type of AUTOCAD Software in cloth
Slope Engraving	360°Slope Can Be Designed Easily
Driving System	Stepper Electrical Motor
Package Dimension	2160X1810X1400 mm
Net Weight	600KGS
Gross Weight	650KGS
Optional Spare Parts	Up-down Worktable, Rotary System, Honeycomb Worktable
Removable Spare Parts	Laser Tube and Lens

This machine is our newest model mainly used for cutting thick materials. It transmit power

by ballscrew, so it can work more stable and the effect of cutting is perfect. It can cut 30mm

acryl,15mm MDF,etc.

Our laser machines could be customized according to your special requirements such as the laser power, dimension of the worktable, the color of the machine and so on.
