♦ Application field
BANRY 28KHz BR-28C2 Multi-functional Ultrasonic Cutting Machine ( Cutter ) is specially for cutting :
1. Thermal plastic ( Plate , sheet , film , laminated material ) ;
2. Carbon fiber ( CFRP ) ;
3. Rubber ( Vulcanized latex , non-vulcanized latex , sheeting materials, tube ) ;
4. Composite materials [( polyethylene fiber , molded articles containing carbon or glass fiber ( GFRP ) ] ;
5. Resin ( ABS ) ;
6. Silicone ;
7. Food ;
8. Foam ;
9. Paper ( Honeycomb paper , Corrugated paper )
10. PVC foam board .
Ultrasonic cutter not only can be used by handle ( Suitable for few material of temporary cutting ) , but also can be used to on robot arm ( Suitable for mass cutting on production line ) .
♦ Quality Assurance and After-sale Service
BANRY Ultrasonic 28KHz BR-28C2 Multi-function cutter is composed of ultrasonic transducer ( converter ) , cover , horn , knife and generator.
♦ Principle of Ultrasonic Hard Materials Cutting
Ultrasonic energy to the vibration of ten million times , cutting and gluing the cutting edge at the same time , so the cutting point will not rough selvedge or fraying like conventional cutting , cutting edge will very smoothly . So it can process all kinds of materials which are hard to cut through ordinary knifes .
Brand / Product |
BANRY / Multi-function Hard Materials Cutter |
Model |
BR-28C2 |
Frequency |
28kHZ |
Cutting Materials |
1. Thermal plastic ( Plate , sheet , film , laminated material ) ; 2. Carbon fiber ( CFRP ) ; 3. Rubber ( Vulcanized latex , non-vulcanized latex , sheeting materials, tube ) ; 4. Composite materials [( polyethylene fiber , molded articles containing carbon or glass fiber ( GFRP ) ] ; 5. Resin ( ABS ) ; 6. Silicone ; 7. Food ; 8. Foam ; 9. Paper ( Honeycomb paper , corrugated paper ) ; 10. PVC foam board . and so on. |
| Cutting Thickness |
1cm-20cm (Normal: 1cm , other size : please contact us for customization) |
Cutting Power |
200W |
Switch |
Foot Switch or External Control |
N.W |
4KGS |
Generator |
analog generator |
Cable |
Standard 2m Special length, please inform us |
♦ Advantage
1. Good smooth cutting edge ;
2. The cuting efficiency is 10 times more than traditional ways , cost savings ;
3. Adopt compressed air to sure working stably for a long time ;
4. Special replaceable knife ( Wear-resistant ) , cost savings ;
5. Simple operation, handle cutting or used for robot arm .
Please click the following pictures to see your interesting products details :
CNC Robot Arm Connection muti-function knife Ultrasonic foam cutting machine 20 kinds materials Ultrasonic knife CNC or Supersonic Portable Ultrasonic knife head CNC Honeycomb corrugated paper cutter cutting machine
