Coal drying machine of lignite coal dryer manufacturer in China
Lignite coal dryer, also known as lignite dryer, is a drying machine mainly used for drying lignite coal.
Working principle of lignite coal dryer:
Lignite coal are sent to hopper of rotary dryer by belt conveyor or bucket elevator. The barrel is installed with slope to horizontal line. Materials enter the barrel from the higher side, and hot air enters the barrel from the lower side, materials and hot air mix together. Materials go to the lower side by gravity when the barrel rotates. Lifters on the inner side of barrel lift materials up and down to make materials and hot air mix completely. So drying efficiency is improved.
On the condition of maintaining the quality of the lignite coal, lignite rotary dryer adopts low-temperature four-level drying technology to evaporate the water containing in the lignite coal to below 13%. The first-level drying area removes most water at the high temperature sate with 400℃ of high temperature, making sure that the chemical component of the lignite coal remains the same and that the lignite coal is not easy to burn; the second-level drying area has the indoor temperature of 300℃, it will remove the water through medium-temperature strong induced air to make sure that the lignite coal do not have coking; the third-level drying area has the indoor temperature of 120℃-210℃, and the crushing device inside the roller will repeatedly hit and scatter the materials and dry them with fair current; the fourth-level drying area is high exhaust area, and the indoor temperature is 60℃-80℃, and the water containing in the materials will be removed by the low-temperature hot airflow with negative pressure of the induced air system.
Lignite coal dryer application:
Lignite coal dryer can dry coal slurry, raw coal, flotation cleaned coal, mixed clean coal, etc.
For coal industry, drying of blast furnace slag, clay, limestone, sand, quartz stone, etc.
For building industry, drying of metal ore concentrate, waste residue, tails, etc.
For beneficiation industry, non thermo-sensitive substance drying.
Lignte coal dryer shipping:
Derui service:
Installation and guidance
When the machine arrives at your company, we will dispatch our technicians to your company to guide the installation and commissioning at site. User should pay for the following fees air tickets, boarding and lodging and traffic in client’s factory. Allowance is about 70USD per day.
Technical training
We provide free technical training service to your stuff. Training content contains the main work principle of machine, operating regulations, maintenance methods and steps, safety, etc.
Warranty: one year (not include man-made damaged).
In order to help you to recommend suitable coal dryer, can you tell me the following information in your inquiry?
1. What is the material you want to dry?
2. What is the moisture of the feed materials?
3. What is the final moisture you want to get?
4.What is the hear source?(firewood, coal, heat gas or electricity)
4. What is the production capacity per hour or per day?
