Coal crushing machine for coal gangue and lignite coal
- 20 Set / Sets per Month
- Qingdao Shanghai Tianjin Lianyungang
- T/T Credit Card
- Tertiary Reversible Impact Hammer Crusher with High Chrome Blow Bar
- China Wheat and Grain Transport Vibrating Feeder Price in Shanghai
- Good Quality Heavy Hammer Crusher for Crushing All Kinds of Ores
- Sand Ore and Coal Vibrating Feeder Machinery Used in Mining Industry
- High Efficiency Stone Crushing Plant Impact Stone Crusher
- Sound Equipment Impact Crusher Machine for Stone Crushing Line
Product Details
Condition: | New | Type: | Hammer Crusher | Application: | Crushing coal, Crushing coal, coal gangue, steel slag,etc. |
Motor Type: | AC Motor | Power(W): | 55+55kw | Capacity(t/h): | 45-60t/ht/h |
Place of Origin: | Henan, China | Brand Name: | Derui | Model Number: | 2PC800*800 |
Dimension(L*W*H): | 3660*1430*1900mm | Weight: | 800kg | Certification: | ISO |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Coal crushing machine for coal gangue and lignite coal
Coal crushing machine applied for coal gangue, furnace slag, cement, pebble, iron ore, lime stone, shale and so on materials' crushing for construction and other industrial materials.
Coal crushing machine characteristics:
1.No screen
2.Material with water content can be crushed
3.up and down two stage rotors for crushing
4.Discharging granularity is uniformity
5.superfine below 2mm
Coal crushing machine hammer:
Coal crushing machine working principle:
When working, driven by two motors,two sets of rotors in series with each other rotating at high speed, in the cavity,materials
crushed by upper rotor and recrushed by lower rotor by rapid rotating, materials collide at high speed in cavity, when finishing
crushing, the discharging size is less than 2mm.
Coal crushing machine technical parameter:
Model | Feeding size | capacity(t/h) | Motor power(kw) | Dimension(mm) |
2PC600*400 | ≤100 | 10-25 | 18.5+18.5 | 2600*950*1860 |
2PC600*600 | ≤110 | 20-30 | 22+22 | 2600*1150*1860 |
2PC800*600 | ≤120 | 35-55 | 45+55 | 3660*1314*1900 |
2PC800*800 | ≤130 | 45-60 | 55+55 | 3660*1430*1900 |
2PC1000*800 | ≤140 | 50-70 | 75+90 | 3950*1750*2280 |
2PC1200*1000 | ≤150 | 70-100 | 110+132 | 4086*2030*2337 |
2PC1400*1200 | ≤180 | 100-120 | 160+160 | 5800*2658*3210 |
2PC1600*1400 | ≤200 | 120-180 | 220+220 | 6000*3100*3900 |
Coal crushing machine application scope:
Coal, coal gangue, slag, steel slag, limestone, coke, galena, siderite, sphalerite, limonite,etc.
Compression resistance is no more than 150MPa
Discharging granularity is fine, moisture content is larger, crushing brittle material
Chemical industry, electric power, aluminium factory, mining, building materials, mineral processing,etc.
About Derui Machinery:
Derui machinery is located in Gongyi city, between Zhengzhou and Luoyang, with convenient transportation.
Main equipment:Ball mill, jaw crusher, Coal crushing machine , rod mill, rotary dryer, rotary kiln, mineral ore processing equipment.
In order to find the suitable Coal crusher and design the best Coal crushing machine for you, please kindly inform us the following information:
1.Which kind of material you are going to crush? Soft stone (dolomite, limestone) or hard stone (granite, basalt, river pebble) ? 2.What's the max input size of the material? (In inch, centimeter or milimeter)
3.What's the granularity of the final products you need? (in milimeter, micron or mesh)
4.What's the production capacity you want? How many tons or cubic meters per hour? 5.You want only a Crusher, or a complete Crushing Production Line?
How to visit us ?
If you want to visit our factory, please note our city name, Zhengzhou City, Henan Province, China(mainland)
Our air port name is : Zhengzhou Xinzheng International air port.
Train station name is: Zhengzhou (Zhengzhou north) train station
