Sawdust continuous carbonization furnace manufacturer from China for biochar
Development prospect:
According to statistics, agricultural and forestry waste(branch, sawdust, rice husk, straw, wood shaving, etc) is about 6-8 billion ton per year, using ratio is only 20%. With economic development, charcoal is needed for industry, agriculture, medicine and daily life. Carbonization equipment is a new kind and economic equipment, it can “turn waste into wealth”-----turn agriculture and forestry waste into coal, recycled by-product wood vinegar fluid and wood tar oil also brings economic value, improved profit. Biomass carbonization project is renewable resource recycling project which is supported by state, it is best choice for business.
Carbonization furnace intorduction:
Raw materials for making carbon:
Wood materials: sawdust, wood chips, rice husks, peanut shells, Stick, plant stalks, bark, scrap, firewood, bamboo wood shavings and
other carbon-containing material (diameter 15mm or less granular)
Nutshell: almond shells, coconut, peach shell, palm shell
Pyrolysis 1 t biomass material can produce flue gas(250-300m3), carbon(250-300kg), wood vinegar(200-250kg), wood tar(30-50kg)
Carbonization furnace consists of feeding system, carbonization systems (hosts and coal discharging equipment),
purification systems, condensate systems, heating systems (gasifier),etc.
Carbonization furnace technical parameter:
Production capacity: 3-5t / d
Host Power: 3kw
Host feed power: 1.5kw × 2
The conveying power: 3kw
Coal discharing machine power: 3kw
Gasifier slag off power: 3kw
Carbon machine of gasifier power: 3kw
Floor space: 15m × 10m × 6m (L × W × H)
Wearing parts: 20 × 20 pure graphite parts , carbon discharging parts, feeding screw blades, burners.
Gasifier diagram:
Working principle of carbonization equipment:
Hypoxia negative pressure high temperature carbonization pipeline carbonization, produced carbon monoxide, mathane, oxygen, by recycling, purification,circulating burning, solved environmental problem and heat source problem.
Carbonization furance diagram:
Carbonization furnace shipping:
Advantages of continuous carbonization equipment:
1. High pressure fan absorb carbon monoxide, mathane, oxygen for recycling.
2. Three layers integrated.
3. Under the function of heat preservation box, carbonization goes smoothly.
4.Combined chain wheel, chain rotation with reducer and adjustable-speed motor, carbonization equipment can work continuously. Adjustable-speed motor applied to different materials, ensure carbon powder quality.
5.Groove equipped with supporting wheel, offering power for continuous carbonization.
6.Screw device ensured materials conveyed from one end to the other end, screw height and screw pitch, ensured production and space for discharging of flammable gas and steam, solved problem of congestion. (Under high temperature, materials produce wood vinegar fluid gas, wood tar oil gas and steam, if it can not discharging in time, may jammed)
7.Screw device make materials heating uniform, continuous production, high quality carbon powder.
8.Sealed box and high temperature graphite fixed in sealed slot, by snap ring and screw bolt, adjust sealing clearance.
Application of carbonization furnace finial product:
Industrial areas:
metallurgy, suitable for the production of high quality steel.
Chemical
Medicine;
Cosmetics;
environmental protection.
The agricultural sector:
Increasing soil temperature, promote seed germination.
Keep the soil moisture.
As release agent for pesticide or fertilizer
The carbon can also change soil pH
Areas of daily life:
As fuel for heating, barbecue, hot pot
Charcoal can eliminate room odors and harmful substances.
Charcoal can also help preserve food, also as refrigerator deodorant
