28THF High Efficiency Woodworking Felt board machine Board Jointing Machine
Application:
Integrated material plate splicing ,solid wood edge banding.wooden door edge banding.
Function:
1.Standard technology efficiency: 2-3mins per board, working efficiency will be more improved than common press machine in winter.
2.Feeding table adopts PVC plate,which will reduce friction,discharge table adopts no power chrome plating roller, high efficiency.
3.Unloading is outside of machine which will be safety and coinvent.
4.oil box length of hydraulic system will be 2570mm,which will be good heat dissipation, avoid high oil temperature shortening hydraulic oil service life. Then improve stability of hydraulic system.
5.Hydraulic pipe jointer adopts inch cone sealing structure, no using sealing ring ,which resolve the oil leaking by using sealing ring .
6.Each oil pressure can be adjusted separately by reducing pressure valve, then realized stable performance, so that it deleted the control pressure meter is out of work problems.
7,Machine rack adopts heavy structure.Then make sure the higher straightness accuracy of finished board
8,High frequency generator installs the high sensitive spark protective circuit, it is effective to protect board damaged.
9.Bug-killing and sterilization
10. Joint plate is high in plainness and quality ,the percentage of outturn is more inproving 5%than the common machine.
11.Convenient handling and low labor intensity
12. Selective heating, glue line heated with low heat in timber, energy saving, little distortion, only cost 15-30KW.h for 1m³board.
13.Assemble varieties of materials such as soft and hard article Board, medium density fiber board, etc.
14.It can check the Higher water content of splicing board material, then ensure the product quality after finishing.
15, it is installed the exported glue clearance sheet on the worktable, which will be easy to clear the rest glue .
16. High frequency generator is outside of HF board jointing machine ,and lays the back of board jointing machine which will be easy to maintain.
Technical Parameter:
Workbench size |
1300 ×2500mm |
working thickness(mm) |
10-50 |
Feeding &discharging mode |
AUTO |
Upper pressure |
9T |
Diameter of upper cylinder |
Φ63 |
upper cylinder number |
2 |
Back pressure |
19 T |
Diameter of Back cylinder |
Φ50 |
Back cylinder number |
7 |
HF generator |
20KW |
Hydraulic rated pressuure(MPa) |
14 |
Product Details:
1. Packaging Details: Stretch film with wooden case or as your request
2.Shipping:We have rich experience in exporting machines to the world and can supply all kinds of different shipping terms!
3.Timely delivery and transportation
1.We have years of manufacturing woodworking machine.OEM and ODM service available.
2. Sample Service :
If you want to test the performance of machine ,we can sent sample to you with cost offer .
3. Customized Service :
Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.
4. After-sale Service
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.
4)Engineers available to service machiner overseas.
Qingdao Steeler woodworking machinery co.,ltd is the professional production of various kinds of sanding machine,
polishing machine and other mechanical equipment manufacturers.The company produced sanding machine which is a combination of Germany,Italy,Taiwan's good mechanical properties,structure and the advanced polishing machine not only draw lessons from the foreign advanced technology,and highlights the Steeler people development innovation, enterprising
spirit,continuous research and development to adapt to the market,make our polishing machine series equipment industry's leading edge products.
We have already approved the ISO9000 International quality system certification and the main products through the national certification,access to the national key new products,high-tech products such as the honorary title,by the Chinese enterprise brand quality committee awarded the "National quality credit AAA grade credit enterprise"brand,the company products are sold well all over the world.
A strong R&D team,strong processing power,the reliable quality assurance,strict testing means make the company to win the trust of users.
Rich experience,sophisticated design,advanced manufacturing technology,as well as relevant to the users'communication,
make the company continuously introduced to adapt to the market,meet the users of the new product. Quality,efficiency,
service,integrity,modest is the goal of the Steeler People!
1) Q: What's the MOQ?
A: MOQ is one set.
2) Q: Provide custom machine Yes or No?
A: Yes. We can provide custom machine for clients.
3) Q: What's the payment terms?
A: T/T 30% in advance and balance before shipment or by negotiation.
4) Q: Are you factory or trade company?
A: We are factory and trade company. STEELER is our brand.
5) Q: How long is the warranty period?
A: One year warranty period except the quick-wear parts.
6) Q: Do you have professional engineers?
A: Yes. We have professional engineers and designers. We can provide OEM products.
