unbelievable performance screw feeder conveyor
- 50 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Homogenization tank B200 external fluidization plate homogenization tank inflation equipment
- B400 Electro-hydraulic sector valve Pneumatic sector valve Block material sector valve can be customized
- Bulk material bulk hangar bottom cement clinker sand aggregate loading inside the wear-resistant ceramics
- Air transport chute XZ400 cement plant ash chute dry ash ore powder transport equipment
- SZT-300 clinker bulk machine sand aggregate bulk head fixed car loader
- Cement depot bottom arc discharge valve B300 pneumatic flow control valve Electric flow control valve
Product Details
Place of Origin: | Shanghai, China | Brand Name: | MANDA | Model Number: | XL vacuum conveyor |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Automatically Truck Loading And Unloading Grain Vacuum Conveyor
The technical parameters of the high quality bucket elevator
Model | XL-3 | XL-5 | XL-10 | XL-15 | XL-20 | XL-30 |
Capacity(t/h) | 3 | 5 | 10 | 15 | 20 | 30 |
Blower Power(kW) | 5.5 | 7.5 | 11 | 15 | 22 | 37 |
Air Locker Power(kW) | 0.75 | 0.75 | 0.75 | 1.1 | 1.1 | 1.5 |
Main Motor Model | Y132S1-2 | Y132S2-2 | Y160M1-2 | Y160M2-2 | Y180M-2 | Y200L2-2 |
Air Locker Motor Model | Y90S-6 | Y90S-6 | Y90S-6 | Y90L-6 | Y90L-6 | Y100L-6 |
Blower Rotating Speed(r/min) | 3300 | 3600 | 4100 | 3700 | 4100 | 4100 |
Air Locker Rotating Speed(r/min) | 60 | 60 | 60 | 60 | 60 | 60 |
Air Pressure(mmH2O) | 940 | 1000 | 1500 | 1600 | 2200 | 3300 |
Air Quantity(m3/h) | 780 | 800 | 1000 | 1600 | 1800 | 1800 |
Stream Speed(m/s) | 26 | 24 | 24 | 25 | 25 | 25 |
Feeding Pipeline Diameter(mm) | 124 | 124 | 150 | 150 | 160 | 160 |
Pipeline Diameter(mm) | 70 | 100 | 124 | 150 | 160 | 160 |
The Longest Conveying Horizontal Distance(m) | 20 | 30 | 50 | 70 | 120 | 170 |
The Longest Suction Distance(m) | 6.5 | 8.5 | 10 | 20 | 30 | 50 |
The Highest Lift Head(m) | 5 | 5 | 8 | 12 | 18 | 30 |
Weight(kg) | 400 | 415 | 460 | 530 | 600 | 900 |
Outline Dimension (mm) in L*W*H | 1780*1050*1550 | 1780*1058*1550 | 1780*1058*1550 | 2080*1148*1800 | 2320*1320*2720 | 2380*1600*2720 |
Introduction of the high quality bucket elevator
XL series high quality bucket elevator
1. Composed of the high pressure blower, air flow control valve, separator tube, air locker, connecting pipe, suction nozzle and conveying pipelines and other components.
2. Working principle:
Negative pressure air stream generated by the high pressure blower though the suction nozzle,suctioning the materials into the hose tube, then materials through the separation tube, air and material separated, material fell off into the air locker downward, then materials will be conveyed to the required place by positive pressure air flow.
3. The air separated will go into the blower through the separator tube (XL-20 and XL-30 through the dust collector).
Advantages of MANDA XL high quality bucket elevator
You can use it at the flowing 3 status:
1st: suction in and pressure conveying out,
2nd: just suck in.
3rd: just pressure conveying out.
The first type of high quality bucket elevator usually use air stream carrying materials through the pipe into the machine then send them to the warehouse trucks and other transportation terminal via a separator. The second type of high quality bucket elevator suck the materials in then let them fall free via the separator and air-lock device to heap or unload into the bag or other conveying equipment.The third type of high quality bucket elevator usually uses a hopper to store the materials need to be conveyed, then convey the materials to the terminal silo or other place.
More Photoes
Private Customized:
We design different pneumatic conveying system according to specific requirement.
Customers’ Guidance:
Please leave the following info in inquiry
1. What’s the capacity ( work load per hour in t/h )?
2.What's the conveying distance?
3. How about the conveying process?
Because with these factors, we are able to give you a fast answer.
Q1: This machine whether can conveying other materials ?
A1: Yes, if it is granular.
Q2: How long will you get the reply ?
A2: Immediately reply on Skype: asd541880 ,
24 hours on email :manda1188 at hotmail dot com.
Q3: The faster way to contact ?
A3: Call +86-18516221729 or +86 2134795600 talk with Rain Dong right now!
