For Sale Hydraulic, Mechanical Metallurgical Residues Ball Press Machine Manufacturer At Competitive Price
- 100 Set / Sets per Month
- Qingdao
- T/T Credit Card PayPal
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Stainless steel handmade sink hydraulic power of light direct press
- Stainless steel handmade sink R corner press machine Electrical box R corner press machine
- DOING supply photovoltaic solar panels recycling machine
- four-axis welding machine for commercial sink panel and bowl
- Double Platform Stainless Steel Kitchen Equipment Polishing Machine
Product Details
Place of Origin: | Henan, China | Brand Name: | ZHONGHANG | Model Number: | GYQ |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Ball Press Machine1. Big capacity and low noise
2. No need adhesive
3. Widely used in ore and mineral powder
For Sale Hydraulic, Mechanical Metallurgical Residues Ball Press Machine Manufacturer At Competitive Price
Products overview:
This series pressing machine is a type of equipment of making powdered material pressed into the ball. Its application is very extensive, and the following materials can be pressure groups, granulation or pressure the ball, such as: aluminum scrap, activated carbon, alumina, bauxite, caustic soda, charcoal, clay, Coke breeze, coal, cryolite, chemical fertilizer, plastic, carbamide, and Potassium salt and so on. The aim is to reduce dust, control capacity, return to the use, and improve transport characteristics. The design of the product is mainly used for let dry powder press into Pidgeon magnesium process of pellet feed.
After years of industrial use and improved, compared with other similar products, this machine has apparent advantages: high making ball rate, less power consumption, compact design for easy assessment, it is undoubtedly an ideal of critical equipment for Pidgeon magnesium process.
To meet the requirements of the material forming, preloading spiral adopts electromagnetic adjustable speed motor. The way to control speed is the hand controlled, the user Can appropriately change the speed of preloading motor to reach the highest ball rate and the maximum capacity according to situation of making balls, after the material pressed is screened by the screening machine, then screen the qualified team for packaging, the rest material can be returned for the bunker and mixed to new material to press groups.
The main technical parameters
Model of machine | GYQ0.5 | GYQ1.0 | GYQ 1.5 | GYQ 2.0 | GYQ 3.0 | GYQ 5.0 | GYQ 6.0 | GYQ 8.0 | GYQ 10 |
Diameter of pressure roller(mm) | φ299 | φ367 | φ367 | φ399.5 | φ522 | φ738 φ700 | φ738 | φ758 | φ858 |
Number of Roller surface slot | 108 | 200 | 200 | 240 | 300 | 504 560 | 504 | 618 | 1000 |
width of roller surface | 180 | 183 | 183 | 252 | 196 | 210 225 | 220 | 225 | 300 |
Model of bearing | 7522 | 2097730 | 2097730 | 2097736 | 2097744 | 2097752 | 2097752 | 2097752 | 35168 |
Number of bearing | 8 sets | 4 sets | 4 sets | 4 sets | 4 sets | 4 sets | 4 sets | 4 sets | 4 sets |
Capacity designed(kg/h) | 500 | 1000 | 1500 | 2000 | 3000 | 5000 | 6000 | 8000 | 10000 |
