Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600

Shangqiu Harmony Machinery Manufacturing Co., Ltd.
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 thumbnail-1
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 thumbnail-2
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 thumbnail-3
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 thumbnail-4
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 thumbnail-5
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 thumbnail-6
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 photo-1
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 photo-2
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 photo-3
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 photo-4
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 photo-5
Low Investment Batch Type Tyre Oil Pyrolysis Plant 2800-6600 photo-6
US$ 28,000 - 46,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Tire Machine
Tire Machine Type:
Tire Recycling Machine
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
lianyungang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Tire Machine
Tire Machine Type Tire Recycling Machine
Place of Origin Henan, China
Brand Name XHZT
Model Number xhzt-2800-6600
Voltage 380V/220v/170v
Power(W) 21-30kw
Dimension(L*W*H) 2800*6600
Weight 35-40 Ton
Certification ISO CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas



 1.Plant major parts:

A.loading plastic into reactor

B. heating reactor

C.after heating , solid plastic converted to oil gas

D.oil gas go into oil-gas separator ,heavy oil deposit and go to heavy oil tank, light oil gas go to cooling system

E. after cooling ,light oil gas change to liquid oil and go into light oil tank

F. non-liquid oil gas will to water sealing tank, then back to combustor burning to heat reactor as fuel

G. smoke produced by heating reactor will go to dedust system, after dedust system treatment , smoke change to white clean waster steam ,then go to sky through chimney.

 low investment batch type tyre oil pyrolysis plant 2800-6600



nology specialty



NO.

Name

Parameter

1

The raw materials:

waste tyres,/plastic, oil sludge

2

Daily capacity:

10 ton/day

3

The size of reactor

2800*6000mm 16mm thickness

4

Reactor material

Q345R

5

Average oil productivity:

30%-80%,

6

Average carbon productivity:

20%-35%

7

Plastic oil rate

30%-80%

8

pyrolysis time

6-8 hours

9

Discharge time

1.5 hour

10

Feeding time

3 hourS

11

Cooling time

3 hours

12.

Working pressure

Normal /slightly negative

13

Power

18 kw

14

Fuel

Coal. Wood, gas etc

15

Working area

1000 square meters

16

Total weight

35 000kgs

17

Reactor rotate speed

0.25-0.4/min

18

Noise

No less than 85DB

19.

Certificate

Ce,.iso,

20.

Carbon slag out

Automatic

 low investment batch type tyre oil pyrolysis plant 2800-6600

3.Work flow:

low investment batch type tyre oil pyrolysis plant 2800-6600

 low investment batch type tyre oil pyrolysis plant 2800-6600low investment batch type tyre oil pyrolysis plant 2800-6600low investment batch type tyre oil pyrolysis plant 2800-6600low investment batch type tyre oil pyrolysis plant 2800-6600low investment batch type tyre oil pyrolysis plant 2800-6600

4.Plastic oil we get

low investment batch type tyre oil pyrolysis plant 2800-6600

5.About us

Shangqiu Harmony Machinery Manufacturting Co.,LTd. is a professional manufacturer engaged in the research, development, production, sale and service of Environmental machines, waste tire/rubber/plastic pyrolysis equipment, waste oil distillation machines, etc.

 low investment batch type tyre oil pyrolysis plant 2800-6600

We have rich experience(8 years experience) in making and installation shangqiu harmony is the top 10 enterprise in disposing waste rubber and plastic.

Now our new tech is crude oil refining and city life trash recycling.

Which convert waste to energy without pollution .

6.Our customer :



Our domestic users

Shandong,Fujian,Hunan,Henan,Yunnan,NeiMonggol,Chongqing,

Hongkong, Taiwan









Oversea users

The Middle East

Iran,Iraq,Lebanon

East Asia

Korea

Europe

Poland,Turkey

Africa

Mauritius

South America

Brazil

Southeast Asia

Malaysia, Indonesia,Vietnam,Philippine,Thailand

South Asia

Pakistan,India



Europ

Italy







low investment batch type tyre oil pyrolysis plant 2800-6600 6.our products:





















Pyrolysis plant

Type

Daily capacity

Used for

Final Product and usage

Batch type

3ton

5Ton

10ton

12ton

15ton

20ton

Waste tyre

Plastic

Rubber

Oil sludge

Oily waste

Others



 Fuel oil



Used for heating boiler as furnace oil

Or refined for distillation oil

Semi-continuous type

15Ton,

20Ton

Fully continuous type

20ton

30ton

60ton

Special type

20Ton

15ton



Distillation plant





Fully continuous type

3ton

5ton

10ton

15ton

20ton

30ton

40ton



Used motor oil

Used lube

Washing parts oil

Pyrolysis oil

Crude oil

Others



A..

base oil

for heavy vehicles



B. diesel for car and other
