simply centrifuge, various centrifuge supplier
SS type three-foot upper discharging centrifuge is of manual top discharge, intermittent operation filtering centrifuge. It is suitable for separating solid particles containing more than 0.01mm suspension, solid particles can be granular, crystalline and other forms are also aaliable for items(such as yarn-beam, textiles, etc)and dehydration. The series of centrifuge is of simple structure, easy operation, and each operation can ba adjusted, residues can be washed, the solid particles are not easy to break, good adaptability. Widely used in chemical industry, light industry, textile, food, pharmaceutical, metallurgy, mining each and environmental protectional industries.
working principle
The material from the top to join the drum under the action of the centrifugal force field, the liquid spreads through the wall of the drum filter into the filter body floor chassis, a liquid outlet from the discharge, and solid materials retained in the drum, removable by hand from the top of the centrifuge from the electrical control, two-speed motor. Can automatically complete a work cycle. That is, start a slow start a high-speed running an electric brake. Can also be used with inverter.
technical parameters
Model |
Rotary drum |
Separation factor |
Motor power |
Total weight |
Overal dimension |
|||
Diameter |
Working volume |
Loading limit |
Rotary speed |
ω2r/g |
KW |
KG |
MM |
|
MM |
L |
KG |
r/min |
|||||
SS300 |
300 |
8 |
10 |
1900 |
819 |
0.75 |
130 |
800x620x500 |
SS450 |
450 |
20 |
25 |
1600 |
725 |
1.5 |
200 |
980x720x625 |
SS600 |
600 |
45 |
80 |
1450 |
755 |
3 |
600 |
1350x990x750 |
SS800 |
800 |
98 |
135 |
1200 |
640 |
5.5 |
1300 |
1740x1380x1000 |
SS1000 |
1000 |
140 |
195 |
1000 |
560 |
7.5 |
1500 |
1950x1560x1050 |
SS1200 |
1200 |
200 |
280 |
800 |
430 |
1.5/11 |
2030 |
2370x1600x1000 |
SS1500 |
1500 |
360 |
400 |
650 |
304 |
15 |
4060 |
3640X1850X1100 |
Centrifugal dryer application.
1. Chemical industry: gypsum, ammonium sulphate, glauber's salt, copper, nickel sulfate, ferric sulfate, sulfur acid, potassium chloride, acetic acid, borax, soda, rubber additives, dyes, pigments, plastic raw materials, soap, grease, various types of resins and other chemical products.
2. The food industry: salt, MSG, food additives, chemical seasoning, starch, sugar.
3. Pharmaceutical: vitamins, antibiotics and other kinds of drugs, herbicides, insect repellents, etc.
4. Mining and metallurgy, copper, zinc, aluminium, mineral and metal refining, etc.
5. Environmental protection: PaiSuan gypsum, water purifying sludge and sewage sludge treatment.
SS600 centrifuge dryer detailed pictures.
All of our products as following,
1. Program-controlled automatic filter press
2. Membrane filter press
3. Hydraulic compress filter press
4. Mechanical compress filter press
5. Jack filter press
6. Cast iron plate and frame/chamber filter press
7. Stainless steel plate and frame filter press
8. Round plate filter press
9. Cotton cake filter press
10. Cardboard filter press
11. DY belt filter press
12. DYX high pressure belt filter press
13. DNY rotary drum thickning/dehydrating belt filter press
14. Triple-belt thickning and dehydrating filter press
15. SS type three-foot upper discharge centrifuge
16. SD type three-foot and filter bag hoist discharge centrifuge
17. PD type filter bag hoist discharge centrifuge
18. Centrifuge of up discharge, three foot, clean series SSB, SB
19. SX type manual top discharge centrifuge
20. PS type manual top discharge centrifuge
21. SGZ type automatic scraper bottom discharge centrifuge
22. PGZ type scarper bottom discharge centrifuge
23. LW series decanter centrifuge
24. Tubular centrifuge
25. Multi-layer stainless steel frame filter
26. Bag filter
27. Diatomite filter
28. Filter late
29. Filter cloth
30. Vacuum disc filter
