Four Heads Fully Automatic Toiletry Perfume Bottle Filling Machine
- 100 Set / Sets per Month
- Shenzhen China
- Credit Card PayPal
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Beverage, Chemical, Food, Other, Medical, Beverage, Chemical, Food, Machinery & Hardware, Medical | Packaging Type: | Bottles |
Packaging Material: | Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220V or 110V customized | Power: | 500w, 500W | Place of Origin: | Guangdong, China |
Brand Name: | OEM | Model Number: | OEM | Dimension(L*W*H): | 2x1.5x1.8m |
Weight: | 450KG | Certification: | ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Four Heads Fully Automatic Liquid Filling Machine
Ask for the manual and operation video when needed!!!!
♦Introduction♦
The HZGZJ-4Y Series Piston-type Filling Machine is used for filling liquid and pasty liquid
products with vairous viscosity in the trades of daily chemical,foodstuffs,medcine,oil etc.
With the employment of the Tainwan's SHAKO electrical elements.
The machine is excellent in quality,lasting and steady in perofrmance and easy in
maintenance.Besideds,the machine,provided with a counter,is accurate in filling volume,
easy in adjustment with no bottle failing to be filled.
In the process of operation,the machine is affected by the following factors:
1.In filling accuracy:Compressed air stability,material uniformity and filling speed.
2.In filling speed:Material Viscosity,cylinder stroke,filling nozzle size and conveyor speed.
♦Operating Principle♦
1.Operating principle:By the reciprocating motion of the pistons in the two material
cylinders of the Model HZGZJ-4Y Filling Machine,negative pressure produces in the front
chamber of the cylinder so that material could be pumped.The stroke of the cylinder is
controlled by a signal valve so as to adjust filling amount and to achieve accurate filling
results.
2.Property:The filling machine with extra functions is designed and manufactured by
our factory with reference to the same kind of foreign machines.This machine is simpler
and easier in operation,error correction,adjustment,cleaning and maintenance.
♦Technical Parameter♦
Voltage | AC 220V,110V can be customized |
Power | 500W |
Filling Range (ml) | 5-120,10-350,30-550,50-1100,250-3100,500-5200 |
Filling Speed | 20-50bottles/min |
Package Size | 2x1.5x1.8m |
Volume Weight | 450kg |
Air Pressure | 0.4-0.6MPa |
Filling Accuracy | +-1% |
Machine Material | 304 Stainless Steel |
Filling Heads | 4 Heads |
♦Pictures♦
♦Tracking Number♦
Tracking number will be informed within 2-3 work days after delivery goods. If you have any problem with it, please leave a message to us.
♦Feedback♦
Any comments, suggestions are accepted. We will be very grateful to your positive footprints left in our company. If you have any problem with our products, please leave a message to us.
♦Refund♦
Any damage or shortage of our goods when you receive your items. Please take some photos for a witness. We will deal with it in 24 hours. Frequently, we will send a new part of items for alternative and heavy-damage, Before refund is accepted, please leave a message to us.
♦About Us♦
1. 30 years of experience of producing filling machines, induction sealing machines and other packing machines.
2. 10 Professional engineers plus 50 workers.
3. Provide high quality products of low prices plus sincere after-sale service.
4. Provide spare parts for free and 1 year warranty.
