Home > Manufacturing & Processing Machinery > Plastic Machinery > Plastic Drying Machine > Infrared Crystal Dryer,moisture 50ppm,energy Saving
US$ 30,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Lianda PET Dryer
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Jiangsu, China
Brand Name
Lianda PET Dryer
Model Number
IRD-500 PET Dryer
Certification
CE ,ISO ,SGS ,FORM A ,FORM E
Warranty
12months
Specifications
1)PET Dryer Less energy consumption2) Final moisture :70ppm
3) Drying time 20min
4) Crystallizer and dehumidifying at a time
PET Dryer/PET pellets and flakes / regrind crystal Infrared dryer / PET dehumidifier
- PET Dryer IRD operates extraordinarily efficiently by direct heat irradiation.
- Energy consumption can be reduced significantly---1/3 of traditional dehumidifier
- Final moisture : 70ppm
- Drying time : 20mins
- Infrared rotating drum IRD is the ideal alternative in the face of steadily rising energy costs.
- The most important components are the radiator module within a horizontal rotating drum, which has an integral, welded, conveyor screw.
- a volumetric metering unit, into the integral screw of the rotating drum, distributing it evenly through the dryer. T
- the drying time depends on the rotational speed of the drum and is adapted precisely to the operational parameters.
- At the end of the rotating drum the material falls into the output hopper and can be transferred directly to the next process step.
Applications:
- Infrared rotating drums IRD – virtually unlimited and plastics and other industries.
- drying of plastic pellets (e.g. PET, ABS/PC, PC, LCP, wood-PP, PP/PE compounds)
- crystallisation and drying of PET, PPS, PLA (reclaim/pellets)
- drying processes with high initial moistures > 1 %
- heating of pellets and reclaim before further processing (e.g. PVC, PE) for example to increase the extruder throughput
- heating processes for removing residual oligomeres and volatile components
- drying in the food, feed and pharmaceutical industries
- roasting of coffee beans.
Specifications:
Infrared crystal dryer | ||||
Electric consumption(KW): | Capacity | Heating | Cooling | Dehumidifying |
80~100kg/h | 9kw | 0.4kw | 0.2kw | |
200kg/h | 12kw | 1.5kw | 0.55kw | |
300kg/h | 21kw | 2.2kw | 1.5kw | |
500kg/h | 30kw | 3.7kw | 3kw | |
1000kg/h | 39kw | 5.5kw | 4kw | |
1500kg/h | 45kw | 5.5kw | 4kw | |
Working voltage: | 380V, 3PHASE, 50HZ(based on customer’s requirements) | |||
Moisture: | 50PPM | |||
Usage material | PET flakes, PET granules/pellets, TPU Particle | |||
Competitive Advantage:
- crystallisation and drying plants for PET pellets and flakes / regrind.
- Granulated foil stock from thermo-forming,
- 100 kg/hr–1500 kg/hr post-consumer bottle reclaim .
- can be mixed with virgin granules – separation does not take place in the rotating drum.
- drying of PLA IRD technology , for virgin, granulated or mixed feedstocks.
- The continual movement of the material in the infrared rotating drum is ideal for, particularly, PLA granulated stock, which tends to easily stick together in the crystallisation phase at T = 60 °C.
- close the melt temperature without agglomerates forming.
- employed in processes in which volatile components or residual oligomeres need to be extracted from the product.
- heating shear sensitive materials before plasticising in the extruder, (especially in cold climates).
Key words:
- Infrared dryers,
- infrared dryer, infrared drier,
- crystal dryer,
- infrared dryer supplier,
- PET crystal dryer,
- PET dehumidifier.
Our service
(1) Your inquiry related to our products or prices will be replied in 24hours.
(2) Our engineer will make machine placement chart according to client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.
