Specifications
Detailed Product Descriptionplastic drying machinery:
1.Supply plastic drying machinery
2Hot air plastic drying machiner
Detailed Product Description
plastic drying machinery:
1.Supply plastic drying machinery
2Hot air plastic drying machinery
3.plastic hopper drying machine
plastic drying machinery:
Website:
Features:
- Uniform Hot air distribution: High heat, significantly shorten drying time;
- Accurate temperature control: Temperature regulator with high accuracy to eiminate error;
- Time & labor saving: isolated tank and hopper, easy material cleaning, simple and quick material changing;
- Reliable design: elegant and solid, easy to install, multiple safeguards to ensure operational safety;
- Increased injection speed: direct blanking to shorten material welt time and increase injection rate.
Specifications:
Model |
Capacity (kg) |
Heater (kw) |
Blower (w) |
Overall Dimensions (cm) |
Model suitable |
Weight (kg) |
MHD-12E |
12 |
1.8 |
50 |
65*40*85 |
1 oz |
25 |
MHD-25E |
25 |
3 |
90 |
75*50*105 |
3oz |
35 |
MHD-50E |
50 |
3.9 |
100 |
90*55*120 |
5-8 oz |
45 |
MHD-75E |
75 |
3.9 |
250 |
95*60*130 |
8-10oz |
50 |
MHD-100E |
100 |
6 |
250 |
100*70*140 |
10-20oz |
70 |
MHD-150E |
150 |
6 |
350 |
110*75*160 |
15-20oz |
80 |
MHD-200E |
200 |
12 |
350 |
120*85*170 |
20-30oz |
120 |
MHD-300E |
30 |
15 |
500 |
145*100*185 |
25-30oz |
120 |
MHD-400E |
400 |
18 |
750 |
150*105*200 |
30-40oz |
230 |
MHD-600E |
600 |
21 |
750 |
150*105*220 |
40-50oz |
250 |
MHD-800E |
800 |
27 |
950 |
150*110*240 |
50-60oz |
300 |
MHD-1000E |
1000 |
30 |
1100 |
185*135*270 |
Over 60oz |
400 |
Model Selection
(A) Model Selection table:
| Model | Molding Machine Suitable |
| MHD-12E | 1 oz |
| MHD-25E | 3 oz |
| MHD-50E | 5-8 oz |
| MHD-100E | 10-30 oz |
| MHD-200E | 30-60 oz |
| MHD-400E | 60 oz. up |
(B) In calculation of hourly injection capacity of molding machine,its selection if based on the following:
Injection capacity per hour x 2.5=loading capacity of dryer
(for instance) how to select a dryer for a molding machine with hourly injection capacity of 20kg?
20kg x 2.5=50kg
In this case,MHD-50E or above should be selected.
Microcomputer control Panel (with timer) :
we reserve right to change specifications without prior notice
