Infrared crystal dryer

Specifications

Infrared drying system
1.Low energy consumption;
2.About10 to 20 minutes' crystallization
3.Final moisture:10ppm~50ppm

Infrared drying system

Operation principle of the Infrared dryer
The drum having wide,shallow spiral channel and paddle inside,can be revolved slowly.The paddle will mix the material while the drum is rotates.The material move ahead gradually along the axis of the drum under push of spiral channel. At the same time the infrared ray which is sent by infrared ray generator and air flow around remove the moisture out of material. The residence time of material staying in the drum is about 20 mins(Residence time depends on actual situation of the material).During this time,the material is not only crystallized but also the moisture has fallen greatly.when PET is used for blowing bottles or other processing whose requirement of moisture is really high,we need additional drying to make sure the moisture.So we equip simple traditional dehumidifier to be acted as buffer hopper before the material

Property:
A.Compared with traditional dehumidifier
Infrared crystal dehumidifier finish the processing:crystal,dehumidifying,drying
at a time.
Short drying time,lower energy consumption,high efficiency.during the
processing of dehumidifying,no breaking the structure of material molecular,to
keep the property of material;We have get German Patent for Infrared crystal dryer
B.Good for drying material:PET, PC original material and recycling material; PE, PP particle; It can be also used for drying waste food and so on.
