Infrared crystal dryer / PET dehumidifier Equipment for PET flake / regrind
Product Feature of Infrared crystal dryer :
We adopt Infrared crystal dryer to dry and crystallize PET Flake instead of Traditional dehumidifier , it saves the energy for a. Dry and crystallize the flake at the same time b. drying time : 20mins c. Final moisture : 50-80ppm
PET Infrared dryer ,PET flakes / regrind rotary drum crystal Infrared dryer / PET dehumidifier Equipment
- crystallisation and drying plants for PET pellets and flakes / regrind.
- Granulated foil stock from thermo-forming,
- 100 kg/hr–1500 kg/hr post-consumer bottle reclaim .
- can be mixed with virgin granules – separation does not take place in the rotating drum.
- drying of PLA IRD technology , for virgin, granulated or mixed feedstocks.
- The continual movement of the material in the infrared rotating drum is ideal for, particularly, PLA granulated stock, which tends to easily stick together in the crystallisation phase at T = 60 °C.
- close the melt temperature without agglomerates forming.
- employed in processes in which volatile components or residual oligomeres need to be extracted from the product.
- heating shear sensitive materials before plasticising in the extruder, (especially in cold climates).
More Detail:
- infrared rotating drum IRD operates extraordinarily efficiently by direct heat irradiation.
- Energy consumption can be reduced significantly.
- infrared rotating drum IRD is the ideal alternative in the face of steadily rising energy costs.
- The most important components are the radiator module within a horizontal rotating drum, which has an integral, welded, conveyor screw.
- a volumetric metering unit, into the integral screw of the rotating drum, distributing it evenly through the dryer. T
- he dwell time depends on the rotational speed of the drum and is adapted precisely to the operational parameters.
- At the end of the rotating drum the material falls into the output hopper and can be transferred directly to the next process step.
Applications of Infrared crystal dryer :
- PET Dryer --Infrared rotating drums IRD – virtually unlimited and plastics and other industries.
- drying of plastic particle (e.g. PET, ABS/PC, PC, LCP, wood-PP, PP/PE compounds)
- crystallisation and drying of PET, PPS, PLA (reclaim/pellets)
- drying processes with high initial moistures > 1 %
- heating of pellets and reclaim before further processing (e.g. PVC, PE) for example to increase the extruder throughput
- heating processes for removing residual oligomeres and volatile components
- drying in the food, feed and pharmaceutical industries
- roasting of coffee beans.
Specifications:
Infrared crystal dryer | ||||
Electric consumption(KW): | Capacity | Heating | Cooling | Dehumidifying |
80~100kg/h | 9kw | 0.4kw | 0.2kw | |
200kg/h | 12kw | 1.5kw | 0.55kw | |
300kg/h | 21kw | 2.2kw | 1.5kw | |
500kg/h | 30kw | 3.7kw | 3kw | |
1000kg/h | 39kw | 5.5kw | 4kw | |
1500kg/h | 45kw | 5.5kw | 4kw | |
Working voltage: | 380V, 3PHASE, 50HZ(based on customer’s requirements) | |||
Moisture: | 100-150PPM | |||
Usage material | PET flakes, PET granules/pellets, PP/PE granules | |||
Key words:
- Infrared driers,
- infrared dryer, infrared drier,
- crystal dryer,
- infrared dryer supplier,
- PET crystal dryer,
- PET dehumidifier.
- PET Dryer
Infrared crystal dryer
Our service
(1) Your inquiry related to our products or prices will be replied in 24hours.
(2) Our engineer will make machine placement chart according to client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.
