Help Center20~95%RH GMP Stability Test/climatic/environmental Chamber
Related Products
-
(150L 250L)FDA Stability/climatic/environmental ChambersNegotiableMOQ: 1 Unit -
(350L 700L)FDA Stability ChambersNegotiableMOQ: 1 Unit
-
(400CFS)FDA Stability/climatic/environmental Test ChamberNegotiableMOQ: 1 Unit
-
Constant Temperature & Humidity ChamberNegotiableMOQ: 1 Unit
-
Drugs Stability ChambersNegotiableMOQ: 1 Unit
(20%RH)GMP Stability Chambers
1,The latest airway system design achieves uniform of temperature and humidity from different parts inside the chamber;Interior material is mirror stainless steel SUS304, no pollution source, easy for clean.
2,Industrial compressor is European original imported completely sealed for high efficiency , low noise, assure machine of long time continuous running .
3,Temperature and humidity integrated sensor is European original imported for high precise, low floating annually. It can test humidity directly , no need of maintenance.
4,Original imported temperature and humidity controller for fast reaction, low deviation of system, high precise control.
5,Standard meets : ICH-2003 Q1(A) CP2010
| Name | Stability Chambers(GMP) |
Stability Chambers (GMP) |
||
Model |
Kingdak-120LGS |
Kingdak-250LGS |
Kingdak-500LGS |
Kingdak-1000LGS |
Temperature Range |
0~65°C |
10~65°C |
||
Accuracy |
±0.5°C |
±0.5°C |
||
Deviation |
±1.5°C |
±1.5°C |
||
Humidity Range |
20~95%RH |
20~95%RH |
||
Accuracy |
±3%RH |
±3%RH |
||
Deviation |
±4%RH |
±4%RH |
||
Control manner |
Temperature and humidity balance Control |
|||
Compressor |
Original Imported industry compressor ( European Union) |
|||
Humidity Sensor |
Original Imported humidity sensor ( European Union) |
|||
Controller |
Original Imported Digital Display Controller( JAPAN) |
|||
Data Recorder |
Optional |
|||
Test point |
40°C 75%RH,25°C 60%RH |
|||
Temperature alarm |
High and low boundary deviation alarm for temperature(Optional) |
|||
Humidity alarm |
High and low boundary deviation alarm for humidity(Optional) |
|||
Dual protections |
Independent overheat protection warning system |
|||
Operating temp. |
+5~35°C |
|||
Internal material |
Mirror surface Stainless steel SUS304 |
|||
External material |
Steel powder coated |
|||
Water tank |
External Water Tank |
|||
Power source |
AC 220V±10% 50HZ |
|||
Safety device |
Compressor and blower overheat protection system, Over temperature protection, overpressure and overload protection for compressor, Water scarcity protection |
|||
Max Power(kW) |
1.5 |
2.5 |
3.0 |
4.0 |
Capacity(L) |
150 |
250 |
500 |
1000 |
Interior dimensions |
600×405×620 |
680×500×730 |
800×700×900 |
900×920×1200 |
External dimensions |
760×830×1480 |
840×870×1550 |
1080×1180×1790 |
1300×1380×1830 |
Trays (standard) |
3 |
3 |
4 |
4 |
Optional |
1,Data record:U disk(with microprinter) or Recorder with paper(with chart drive) |
|||
Remark |
Please confirm whether the external dimension of this model chamber can be smooth for elevator,corridor or gate, whether there is enough space for it in lab. |
|||
