K Series Smart Refrigerated and Heating Circulator/Water Circulator

K Series Smart Refrigerated and Heating Circulator/Water Circulator thumbnail-1
K Series Smart Refrigerated and Heating Circulator/Water Circulator photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
KINGDAK
Model Number:
K Series
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Kingdak Industries Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name KINGDAK
Model Number K Series
Place of Origin Shanghai, China

K Series Smart Refrigerated and Heating Circulator/Water Circulator



Characteristics:
  • Fuzzy PID temperature control system: control temperature stability accurately and fast.
  • Multi-protection: Over-current protection, high and low temperature warning functions, dry-running protection.
  • Convenience function: Parameters memory function, temperature correction.
  • ECO-refrigerant R134a and high quality compressor guarantee the cooling system ecofriendly and powerful
  • Low Noise design: use high quality compressor and mute pump.
  • Robust water tank: ultra-slushing and rust-proof
  • Bright LCD temperature display
  • Compact design, removable venting grid for convenient cleaning to maintain cooling performance and drain off water

Application:

Experiment that need heating and cooling.
Fermentation Tank
Polarimeter
Refractometer
Spectrophotometer
Electrophoresis System
Chromatographic Column
Viscometer
Rotation Evaporation Instrument
Rheometer

Technical data:




KCL6-05

KCH6-05

KCL6-20

KCH6-20

KCL6-35

KCH6-35

Working temperature range

-5 °C ~ 100 °C

-5 °C ~ 200 °C

-20 °C ~ 100 °C

-20 °C ~ 200 °C

-35 °C ~ 100 °C

-35 °C ~ 200 °C

Temperature control

PID

*

*

*

*

*

Temperature stability

±0.03 °C

*

*

*

*

*

Temperature sensor

PT100

*

*

*

*

*

Display resolution

0.1 °C

*

*

*

*

*

Heater capacity

2000 W

*

*

*

*

*

Cooling capacity

250W

*

*

*

*

*

Refrigerant

R134a

*

*

*

*

*

Pump capacity Pressure

0.35 bar

*

*

*

*

*

Pump Flow rate

10L/min

*

*

*

*

*

Ambient temperature

-20 ~ 70 °C

*

*

*

*

*

Filling volume liters

6L

*

*

*

*

*

Bath opening L x W (cm)

16x 16

*

*

*

*

*

Bath dimensions L x W x H (cm)

32 x 18 x 15

*

*

*

*

*

Dimensions L x W x H (cm)

40 x 25 x 65

*

*

*

*

*

Power supply

220VAC±10% 50Hz

*

*

*

*

*

Weight (kg)

25

*

*

*

*

*
