Food processing industrial use frozen sweet corn production line
- 5 Set / Sets per Month
- Ningbo /Shanghai
- T/T
Product Details
Condition: | New | Place of Origin: | Zhejiang, China | Brand Name: | guanfeng |
Model Number: | GP-I | Type: | Other, frozen sweet corn production line | Voltage: | 380V |
Power(W): | 75kw | Weight: | 50T | Dimension(L*W*H): | 80x4.2x4.0m |
Certification: | ce | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Frozen Sweet corn production line
Main Application: This processing line is mainly used for pretreatment processing and IQF frozen for sweetcorn products;
Capacity: from 500kg/hr to 3000kg/hr for single processing line;
Main processing flow:
1. Peeling --> 2. Threshing --> 3. Maiz ear removing --> 4. Washing --> 5. Blanching---> 6. Chilling --> 7. Dewatering --> 8. IQF freezing.
Main equipments:
Peeling
Threshing
Washing and blanching line
IQF freezing line
No. | Equipment Name | Equipment Description |
1 | GTS Elevating feeder | > Stainless steel construction; > Stainless steel mesh belt; |
2 | GBP sweet corn peeling machine | > Stainless steel construction; > 16/32 rollers; |
3 | Waist conveyor | > SUS304 stainless steel construction. |
4 | SCT-633 Sweet corn thresher | > SUS304 stainless steel construction. |
5 | Material conveyor | > Stainless steel construction; > Stepless speed manural control |
6 | Elevating conveyer | > Stainless steel construction; > Stainless steel mesh belt; |
7 | Multilayer circulation conveyor | > Stainless steel construction; > Stainless steel mesh belt; |
8 | Roller washing machine | > Stainless steel construction; > Stainless steel mesh belt; |
9 | FCJ winnowing machine | > SUS304 stainless steel construction. > Speed and blower volume frequency control; |
10 | Elevating conveyer | > Stainless steel construction; > Stainless steel mesh belt; |
11 | GQX-M Bubble washing machine | > SUS304 stainless steel construction. > Stainless steel mesh belt; |
12 | BL belt blancher | > SUS304 stainless steel construction. > Stainless steel mesh belt; |
13 | Water chiller | > SUS304 stainless steel construction. > Stainless steel mesh belt; |
14 | Ice Water chiller | > SUS304 stainless steel construction. > Stainless steel mesh belt, width; |
15 | Vibration dewater machine | > SUS304 stainless steel construction. > High grade vibration motor with corrosion resisting rubber spring. |
16 | Elevating conveyer | > SUS304 stainless steel construction. > Stainless steel mesh belt. |
17 | Vibration feeder | > SUS304 stainless steel construction. > High grade vibration motor with corrosion resisting rubber spring; |
18 | GLZ IQF freezer | > Input material temperature:+15°C > Output material temperature: -18°C |
Seaworthy packing with steel frame for big machienry. Wooden or plywood carton packing for accessories and fittings.
1) Food processing technology consultency;
2) Working flow layout design;
3) Plant layout for processing line equipments;
4) Onsite guide of installation and commissioning;
5) Training for local operators;
6) After sales technical support.
GUANFENG MACHINERY is located in the Yangtze River delta, Shangyu city, Zhejiang province with the most convenient transportation and prosperous economic in China, 1 hour by car to Hangzhou or Ningbo and 2 hours from Shanghai.
Our company was established by a group of experienced and dedicated engineers who are excited and specialized in finding the best solutions to improve the food processing equipments therefore bring value to the food processors and make better quality food products. Based on the market demands and our technology background, we focus on the developing and manufacturing equipments for IQF frozen food industry, vegetables and fruits dehydration, Freeze drying (FD), and food processing lines for various vegetables, fruits and seafood industry.
We value "honesty, innovative and quality" because we know that we are not only supplying equipment to our clients but the partners to help our clients to get a better result. Keeping this in our mind, we not only make high quality food processing equipment, but also help the clients to figure out the optimum processing work flows, make amendments according to client's specific needs, training staffs for the user of our equipment and even more, because we believe that our users or clients' success is the foundation of ours.
