Sealed Sample Crusher/ Small Size Sealed Sample Crusher/ Laboratory Sealed Sample Crusher/Grinder For Sample Preparation

Specifications

1. High frequency vibration grinding,
2. High efficiency of comminution with uniform particle size.
3. No blending of samples

1. High frequency vibration grinding,

2. High efficiency of comminution with uniform particle size.

3. No blending of samples

4. No need of screening and contraction.

 5. Energy conservation and environment protection

6. All products through the ISO certification







It serves to crush materials and prepare samples without pollution in laboratories of institutes in the rade of geology, mine, metallurgy, coal, chemical industry and building materials and so on. The machine contains an automatic dust remover.

CGJ,CGF Model Sealed Serial Laboratory Sampling Crusher adopting compact earthen bowl loosening proof device is light weight and reliable. With full enclosure and no dust spillover, it requires no air-exhausting and dusting system. It features high frequency vibration grinding, high efficiency of comminution with uniform particle size. no blending of samples and no need of screening and contraction. Users can select the different varietes of products based on the sample volume.

Model	cups number	capaticy(g)	Feed size(mm	Output size(mm	Crusher time(minute	Power(kw	Weight(kg
CGJ-100/1	1	100	13	0.074	2-3	1.1	160
CGJ-100/2	2	200	13	0.074	2-3	1.1	170
CGJ-100/3	3	300	13	0.074	2-3	1.5	180
CGJ-100/4	4	400	13	0.074	2-3	1.5	200
CGJ-100/5	5	500	13	0.074	2-3	1.5	200
CGJ-100/7	7	700	13	0.074	2-3	1.5	200
CGJ-200/1	1	200	20	0.074	3-5	1.5	160
CGJ-200/2	2	400	20	0.074	3-5	1.5	170
CGJ-200/3	3	600	20	0.074	3-5	1.5	180
CGJ-200/4	4	800	20	0.074	3-5	1.5	200
CGJ-400/1	1	400	26	0.074	3-5	1.5	200
CGJ-400/2	2	800	26	0.074	3-5	1.5	210
CGJ-400/3	3	1200	26	0.074	3-5	1.5	220
CGJ-400/4	4	1600	26	0.074	3-5	1.5	230
CGJ-500/1	1	500	30	0.074	3-5	1.5	260
CGJ-1000/1	17	1000	30	0.074	3-5	1.5	300
