Home > Products > other machinery > mining ore mineral table concentrator
mining ore mineral table concentrator
- Guangzhou
- T/T
You May Like
Product Details
| Condition | New | Type | Other, shaking | |
| Place of Origin | Jiangxi, China | Brand Name | Oasis | |
| Model Number | 6S | Certification | ISO9001:2008 |
Product Description
We have three styles of deck depend on the different particle size of raw ore. Coarse Ore Deck, Fine Sand Deck and Slime Deck. The decks are constructed of steel framework and covered fiberglass with corundum, this cover its strength reaches as high as 70% of steel, the features of this design are stronger, wear-resistant, Corrosion-resistant, and no distortion, it lengthens the working-life of machine and thus allows machine perform perfectly on different mineral and different weather condition.
Support device:
We have three supporting device types: Tradition type, groove steel support and big channel steel support, The groove support and. Big channel steel support are easy to installation and move.
Technical Parameters
Model | 6-S | 6-S | 6-S | LY | |
Deck Size | Length(mm) | 4500 | 3000 | 2100 | 1100 |
Transmission end width(mm) | 1850 | 1620 | 1050 | 500 | |
Concentrate end width(mm) | 1560 | 1110 | 850 | 430 | |
Beneficiation area(m2) | 7.67 | 4.08 | 2 | 0.51 | |
Feeding Size (mm) | Coarse sand Deck | 2-0.5 | 2-0.5 | 2-0.5 | 2-0.5 |
Fine sand Deck | 0.5-0.1 | 0.5-0.1 | 0.5-0.1 | 0.5-0.1 | |
Slime Deck | 0.1-0.037 | 0.1-0.037 | 0.1-0.037 | 0.1-0.037 | |
Feeding amount (t/h) | Coarse sand Deck | 1-2 | 0.6-1.5 | 0.4-0.8 | 0.1-0.2 |
Fine sand Deck | 0.5-1 | 0.3-0.8 | 0.2-0.5 | 0.05-0.1 | |
Slime Deck | 0.3-0.5 | 0.2-0.4 | 0.1-0.2 | 0.03-0.05 | |
Feeding Density (%) | 10-30 | 10-30 | 10-30 | 10-30 | |
Water Added (t/h) | 0.5-3 | 0.3-1.5 | 0.2-1 | 0.1-0.5 | |
Stroke (mm) | 8-36 | 10-30 | 12-28 | 9-17 | |
Frequency (F) | 240-380 | 240-420 | 240-450 | 280-460 | |
Transverse slope of Deck | 0°-5° | 0°-8° | 0°-10° | 0°-10° | |
Motor | Model | Y70L-4 | Y100L-4 | Y90L-4 | Y80L-4 |
Power (kw) | 1.1 | 1.1 | 1.1 | 0.55 | |
Weight (t) | 650 | 550 | 350 | 150 | |
