Specifications
1. simple structure2. easy maintenance
3. high efficiency
4.best price&timely delivery
Parameter of laboratory Wet Strong-intensity Magnetic Separator
XCQS Wet High Intensity Magnetic Separation Machines for metal mineral processing laboratory, mining engineering experiment, the middle experimental plant, which uses fine-grained wet method magnetic ore separator, only a small amount of sample can be tested technical indicators of mineral iron content. Separator small size, easy to operate. The device is not suitable for beneficiation test with a corrosive liquid. This product is the only designated former Ministry of Geology and Mineral production, the implementation of industry standards.
The role of large area magnetic machine, processing capacity, tooth plate made of Poly magnetic media, magnetic field intensity and magnetic field gradient is high, the low-grade iron ore oxidation experiments very effective.
Model |
Uite |
XCSQ 50/70 |
|
Size of separating tank |
mm |
50/70/220 |
|
Coil cooling method |
r/min |
Forced air cooling |
|
Caparating size |
kg/h |
4-5 |
|
Feed size |
mm |
1 |
|
Intensity |
GS |
23000(1840KA/m) Adjustable steplessly |
|
Voltage |
V |
380 |
|
Overall consumed power |
kw |
0.4 |
|
Excitation power |
input |
|
220V,50HZ |
output |
|
0-118V,1-25A |
|
Overall dimensions |
mm |
783/600/1200 |
|
Weighe |
kg |
250 |
|
