Author: Shicheng Oasis Mineral Equipment Factory
Magnetic iron ore
Metallic mineral ores with magnetite-based, followed by hematite, siderite; gangue minerals are: quartz, chlorite, amphibole, mica, feldspar and calcite.
Jingtieshan-type iron ore are mainly distributed in China's northwest Gansu province, the main metallic mineral ores mirror iron ore, siderite, etc. symbiotic valuable mineral barite. Main metal ores containing vanadium and titanium minerals are magnetite, ilmenite, sulfide in order to mainly pyrrhotite.
According to the different iron minerals, industrial value of iron ore are: magnetite stone, red iron ore, brown iron ore, siderite iron ore and mixed ore (magnetite, hematite, a mineral mix , titanium magnetite stone, copper-magnetite stone) and so on.
Source:
Magnetic wet drum separator for semi-backflow tank
1)Simple installation and adjustment magnetic separator
2)Easy to operate
3)Permanent magnetism...
Monocular wet to do a half turn counter-current magnetic drum magnetic separator Magnetic wet drum separator for semi-backflow tank
The CTB / S / N magnetic separator is mainly used for wet weak magnetic sorting or remove fine particles strong magnetic minerals, widely used in mineral processing, coal preparation and chemical industries. In the wet magnetic separation operations, if the access to clean magnetic minerals, usually selected downstream-type magnetic separator (for less than 6 mm); if required to maximize the recovery of magnetic minerals, then the selection of reflux-type magnetic separator (for less than 0.8 mm); when the drug taking into account the grade and recovery of magnetic minerals, when to use semi-reflux separator (for less than 1 mm), magnetic field strength from 100 gauss to 6800 gauss between the
1 Tesla (T) = 1000 mT (mT) = 10000 gauss (Gs)
