Lab Saw-Tooth Wave Jig/ Wash Box/ Lab Jigging Machine/jig Concentration/ Jig Separator

Lab Saw-Tooth Wave Jig/ Wash Box/ Lab Jigging Machine/jig Concentration/ Jig Separator photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other
Capacity(t/h):
As per specific type
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou/xiamen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other
Capacity(t/h) As per specific type
Place of Origin Jiangxi, China
Brand Name oasis
Model Number XCT
Certification ISO9001:2008

Specifications

1.easy maintenance
2.even final particles
3.high crushing ratio
4.firm structure...

ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-797-5745599

Product Name: 100 × 150 diaphragm jig

Main application areas:

Diaphragm Jig is a kind of gravity concentrator, gravity dressing is based on the proportion of ore is different settling velocity in the medium is also different, the difference between the use of mineral weight, while the completion of a mixture of layered mineral particles sorting work.

Diaphragm Jig is suitable for sorting ferrous and nonferrous metals, chemicals, construction and other aspects of experimental research.

Main technical parameters and specifications Model

Jigging chamber size

Length (mm)

 150

Width (mm)

100

Jig room number (a)

2

Jig room area

0.03

Eccentric Maximum stroke (mm)

0-20

To mine the largest size (mm)

0-3

Chong times per minute (beats / min)

420

Handling capacity (approximately) (t / h)

0.02-0.7

Screen the maximum amount of water (approximately) (l / sec)

0.117

Screen in Sheung Shui, the maximum amount (about) (l / sec)

0.10

Motor

Power (kW)

0.55

Speed (r / min)

1400

Dimensions

Length

mm

760

Width

530

Height

1320

Total weight (kg)

175
