Specifications
1. Easy operation2. Good price with perfect quality3. Strong working ability4. All products through the ISO certification
XFD Series Single Flotation Cell is provided for flotation of minor ore samples in labs of geological, metallurgical, chemical and other industries. XFDII second-generation new product has a variable frequency technology, digital display, adjust the precise, reliable operation and so on.
XFDIII third-generation new product has a variable frequency technology, digital display, adjust the precise, reliable operation characteristics, and the other heat pipes, temperature control device, at any time control, display tank mine fluid temperature, plus automatic adjustment of fill with water, automatic drug delivery devices such as
Model | Volume of tank | Impeller diameter | Impeller speed | Scraper speed | Power | Overall dimensions | Weight |
particle size0.2 mm | L | mm | r/min | r/min | w | mm | kg |
XFD0.5L | 1.5 | 45 | 2130-2590 | 15/30 | 90 | 635/338/700 | 30 |
XFD0.75L | 0.75 | 45 | 2130-2590 | 15/30 | 90 | 635/338/700 | 30 |
XFD1L | 1 | 55 | 1700-2100 | 15/30 | 90 | 635/338/700 | 30 |
XFD1.5L | 1.5 | 60 | 1590-1910 | 15/30 | 90 | 635/338/700 | 33 |
XFD3L | 3 | 70 | 1544-1890 | 8/20 | 120 | 683/350/822 | 50 |
XFD8L | 8 | 100 | 1400 | 8.6/13/17 | 250 | 740/350/867 | 71 |
