Laboratory sealed Sampling preparation Crushers
It serves to crush materials and prepare samples without pollution in laboratories of institutes in the rade of geology, mine, metallurgy, coal, chemical industry and building materials and so on. The machine contains an automatic dust remover.
CGJ,CGF Model Sealed Serial Laboratory Sampling Crusher adopting compact earthen bowl loosening proof device is light weight and reliable. With full enclosure and no dust spillover, it requires no air-exhausting and dusting system. It features high frequency vibration grinding, high efficiency of comminution with uniform particle size. no blending of samples and no need of screening and contraction. Users can select the different varietes of products based on the sample volume.
Model | cups number | Capaticy(g/system)
| Feed size(mm | Output size(mm | Crusher time(minute | Power(kw | Weight(kg |
CGJ-100/1 | 1 | 100 | 13 | 0.074 | 2-3 | 1.1 | 160 |
CGJ-100/2 | 2 | 200 | 13 | 0.074 | 2-3 | 1.1 | 170 |
CGJ-100/3 | 3 | 300 | 13 | 0.074 | 2-3 | 1.5 | 180 |
CGJ-100/4 | 4 | 400 | 13 | 0.074 | 2-3 | 1.5 | 200 |
CGJ-100/5 | 5 | 500 | 13 | 0.074 | 2-3 | 1.5 | 200 |
CGJ-100/7 | 7 | 700 | 13 | 0.074 | 2-3 | 1.5 | 200 |
CGJ-200/1 | 1 | 200 | 20 | 0.074 | 3-5 | 1.5 | 160 |
CGJ-200/2 | 2 | 400 | 20 | 0.074 | 3-5 | 1.5 | 170 |
CGJ-200/3 | 3 | 600 | 20 | 0.074 | 3-5 | 1.5 | 180 |
CGJ-200/4 | 4 | 800 | 20 | 0.074 | 3-5 | 1.5 | 200 |
CGJ-400/1 | 1 | 400 | 26 | 0.074 | 3-5 | 1.5 | 200 |
CGJ-400/2 | 2 | 800 | 26 | 0.074 | 3-5 | 1.5 | 210 |
CGJ-400/3 | 3 | 1200 | 26 | 0.074 | 3-5 | 1.5 | 220 |
CGJ-400/4 | 4 | 1600 | 26 | 0.074 | 3-5 | 1.5 | 230 |
CGJ-500/1 | 1 | 500 | 30 | 0.074 | 3-5 | 1.5 | 260 |
CGJ-1000/1 | 1 | 1000 | 30 | 0.074 | 3-5 | 1.5 | 300 |
