Specifications
Hign-strength Raymond millThe machine is used for grinding the barite, limestone, kaolin, cerames, and slags, etc, below scale
Working process:
In the main frame, a 100-1500 kg powered pressure spring is fixed to the roller suspender. After the grinder is put into effect, the roller rotates around the main shaft, and rolls closely against the ring pressed by the high pressure spring and centrifugal force. And its rolling pressure ration is 1.2 times higher than that of the raymond grinder under the same power condition and the production output is raised to substantial degree.
When a certain degree of wear of roller and ring is effected, it is recommended to adjust the length of the spring to maintain the constant pressure between the roller and the ring. As a result, the stable output and fineness are ensured.
Technical parameters of Impact crusher
Type parameter |
6R4525 |
5R4119 |
4R3216 |
3R90 4R90 |
3R85 4R85 |
3R75 |
3R65 |
|
|
|
3R60 |
Particle size of feed (mm) |
<=30 |
<=25 |
<=25 |
<=25 |
<=20 |
<=20 |
<=15 |
|
|
|
<=15 |
Particle of finished product(mm) |
0.125-0.044 |
0.125-0.044 |
0.125-0.044 |
0.125-0.044 |
0.125-0.044 |
0.125-0.044 |
0.125- 0.044 |
|
|
|
|
shift output at different material fine degree(t/8h) |
16-120 |
8-60 |
4-45 |
3-35 |
2-28 |
1.5-20 |
1-18 |
|
|
|
|
Rotate speed of central shaft (r/min |
82 |
105 |
130 |
160 |
160 |
160 |
180 |
|
|
|
|
Inner diameter of pulverzing ring (mm) |
1770 |
1400 |
1073 |
973 |
885 |
865 |
725 |
|
|
|
|
Diameter of pulverzing roller(mm) |
450 |
410 |
320 |
300 |
270 |
260 |
210 |
|
|
|
|
Height of pulverizing ring(mm) |
250 |
190 |
160 |
160 |
150 |
150 |
150 |
|
|
|
|
Main Motor(kw) |
y315m-4-32 |
y280s-4-75 |
y225s-4-37
|
y225m-8-30 |
y225m-8-22 |
y225s-8-18.5 |
y200L-8 -15 |
|
|
|
|
Fan Motor(kw) |
y315m-4-132 |
y250m-4-75 |
y200L-4-37
|
y180m-4-22 |
y160L-4-15
|
y160L-4-15 |
|
|
|
|
|
Motor(kw) |
y160m-4-11 |
yc200-4B-7.5 |
yc120-4A-5.5
|
y112m-6-2.2
|
y112m-6-2.2 |
y112m-6-2.2 |
|
|
|
|
|
