Specifications
Hign-strength Raymond mill Advantage:1)High efficiency
2)Fine product
3)Simple structure
The machine is used for grinding the barite, limestone, kaolin, cerames, and slags, etc, below scale 9.3 of Mohs hardness and 280-odd sorts of non-inflammable and non-explosive stuff in the trades of mining, metallurgical industrial, chemical engineering and building material for high fine powder generation and processing. The product size is adjustable in the range of 80-425 (1000 the finest) meshes. It is possible to product 30-80 mesh coarse powder through special device in the machine.
Type parameter | 6R4525 | 5R4119 | 4R3216 | 3R90 4R90 | 3R85 4R85 | 3R75 | 3R65 |
Particle size of feed (mm) | <=30 | <=25 | <=25 | <=25 | <=20 | <=20 | <=15 |
Particle of finished product(mm) | 0.125-0.044 | 0.125-0.044 | 0.125-0.044 | 0.125-0.044 | 0.125-0.044 | 0.125-0.044 | 0.125- 0.044 |
shift output at different material fine degree(t/8h) | 16-120 | 8-60 | 4-45 | 3-35 | 2-28 | 1.5-20 | 1-18 |
Rotate speed of central shaft (r/min | 82 | 105 | 130 | 160 | 160 | 160 | 180 |
Inner diameter of pulverzing ring (mm) | 1770 | 1400 | 1073 | 973 | 885 | 865 | 725 |
Diameter of pulverzing roller(mm) | 450 | 410 | 320 | 300 | 270 | 260 | 210 |
Height of pulverizing ring(mm) | 250 | 190 | 160 | 160 | 150 | 150 | 150 |
Main Motor(kw) | y315m-4-32 | y280s-4-75 | y225s-4-37
| y225m-8-30 | y225m-8-22 | y225s-8-18.5 | y200L-8 -15 |
Fan Motor(kw) | y315m-4-132 | y250m-4-75 | y200L-4-37
| y180m-4-22 | y160L-4-15
| y160L-4-15 |
|
Motor(kw) | y160m-4-11 | yc200-4B-7.5 | yc120-4A-5.5
| y112m-6-2.2
| y112m-6-2.2 | y112m-6-2.2 |
|
