The equipment mainly comprises420/450 Grate Ball Mill,150/1200 Screw Classifier,35 liter Swing Feeder and 90/600 Screw Conveyor and can conduct grinding operation continuously in a close circuit.
Equipment, factory, had installed electrical equipment and water supply systems, installation, without a separate base.
According to the materials handled by the nature and size characteristics of the pulverized product specific requirements, optional three different processes, respectively grinding: 1. Pre-grinding, inspection classification; 2. Pre-graded sand and then back to grind ; 3. start grinding.
Grinding and classification unit contains a lattice-type ball joint, spiral classifier, tilting feeder, screw conveyor, can be continuous closed-circuit grinding work
According to different requirements of mineral nature, can choose three different grinding processes, a pre-grinding, inspection classification 2, pre-grading, back to sand in the mill, 3, started grinding
Its technical parameters are as follows:
Model | Capacity | Feed size | Output size | Power | Overall dimensions | Weight |
| Kg/h | mm | mm | kw | mm | kg |
XMQL420/450 | 45-90 | 5-10 | Can control grinding to 95%-0.074 | 2.12 | 1630/1260/1730 | 800 |
Co-grinding and classification units | |||||
To the ore size | 5-10 | Mm | |||
Product size | Can be controlled grinding to 95% -0.074 | Mm | |||
Capacity | 45-90 | Kg / h | |||
Equipment total power | 2.12 | KW | |||
Size | 1630/1260/1730 | Mm | |||
Total weight | 820 | Kg | |||
420/450 lattice-type ball mill | |||||
Shell Size | 420/450 | Mm | |||
Cylinder volume | 60 | L | |||
Cylinder speed | 57 | Rev / min | |||
Weight of ball | 20-25 types of steel ball | 10 | Kg | ||
25-30 types of steel ball | 20 | Kg | |||
3 30-35 types of steel ball | 30 | Kg | |||
35-40 types of steel ball | 40 | Kg | |||
To the ore size | 5-10 | Mm | |||
Product size | Can be controlled grinding to 95% -0.074 | Mm | |||
Capacity | 45-90 | Kg / h | |||
Power | 1.5 | KW | |||
150/1200 Spiral Classifier | |||||
Screw Size | 150/1200 | Mm | |||
Spillway width | 240 | Mm | |||
Angle adjustment range | 10-30 | Degree | |||
Screw Speed | 18,23,30 | Rev / min | |||
Sand back the amount of | 500 | Kg / h | |||
Overflow traffic | 260 | Kg / h | |||
Power | 0.25 | KW | |||
35L Swing feeder | |||||
Ore storage capacity | 35 | L | |||
Oscillation frequency | 19 | Rev / min | |||
To mine the speed | 6-200 | Kg / h | |||
Electric Machine | Power | 0.12 | KW | ||
Speed | 1400 | Rev / min | |||
90/600 screw conveyor | |||||
Spiral Specifications | Diameter | 90 | Mm | ||
Length | 600 | Mm | |||
Screw Speed | 23 | Rev / min | |||
Power | 0.25 | KW | |||
