Specifications
High concentration ratio ,High recovery ratioit is one of the main equipments of gravity concentration.(Mob:008613697077005)
ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-13697077005 )is production
Double Shaker
For tungsten, tin, tantalum and niobium, gold, iron, manganese and other metals, ferrous metals, nonferrous metals, precious metals and other minerals and coal sorting. . This product is the only designated former Ministry of Geology and Mineral production, the implementation of industry standards.
Traditional shaker covers an area of large, relatively low processing capacity, customer investment increases, double-shaker covers an area of inconvenience to deal with a large amount of equipment, low cost,
Shaker is available in the double-sweep the election, featuring various operations, sorting coarse sand (2-0.5 mm), fine sand (0.5-0.74), sludge (0.074) different grain level,
Shake surface structure of grit, sand, sludge of the points, there are 46 specific sub-slot, 60-slot dual-Qu Bo, 60-slot single-Qu Bo, 80 slots, 90 slots, 110 slot, 120 slot, lifting of bed, etc. materials were glass, steel or wood shaker surface.
The same bed with hyperbolic rocker mechanism, the spring box in the shaker box, the crankshaft, rod, springs, rocker and so increase the size, material unchanged. On the lower dimensions are 1823/1558/4520. On the lower bed sharing a set of lower bed slope adjustment device used in shake liner support,
Model |
Unit |
LY4500/1850 |
Bed Size |
mm |
4500/1850/1560 |
Stroke |
mm |
6-8 |
Times of stroke |
r/min |
240-380 |
Slope |
o |
0-10 |
|
Feed size |
Mineral sand mm |
2 |
Mineral slime mm |
0.02 |
|
Feed density |
% |
10-30 |
Need Water t/h |
t/h |
0.4-0.7 |
power |
kw |
1.5 |
Capacity size |
Mineral sand t/h |
3-3 |
Mineral slime t/h |
1.6-2.5 |
|
Overall dimensions |
mm |
5600/1820/15600 |
Weigh |
kg |
1650 |
