ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-797-5745599 )are production
Spiral Chute which combines the advantages of spiral concentrator, shaking table and centrifugal concentrator, is a new beneficiation equipment with the advanced level.
It is applicable for separation of granularity ranged from 4mm to 0.02mm metallic minerals such as iron, ilmenite, chromite, tungsten-tin ore, niobium-tantalum ore, gold placer, seashore monazite, rutile and zircon as well as other metallic and non-metallic minerals with adequate difference of specific gravity.
Spiral Chute is made of the fiberglass lined with wear-resistant polyurethane and corundum cover; the advantages are small footprint, without power, moisture proof, anti-rust, wear proof, anti corrosion and no noise, properly suitable for the different feeding particle sizes. it is especially for concentrating sand ore in beach, riverside, seashore and stream.
Features:
High recovery ratio, High efficiency beneficiation
Small footprint, Without power
Low operating cost and long working life
Widely use range
Simple installation and easy maintenance
Rust and corrosion resistant;
No noise and no pollution,
Model |
BLL-2000 |
BLL-1500 |
BLL-1200 |
BLL-900 |
BLL-600 |
BLL-400 |
|
|
Spiral Diameter (mm) |
2000 |
1500 |
1200 |
900 |
600 |
400 |
|
|
Spiral Pitch (mm) |
1200 |
720/540 |
720/540 |
675/540 |
450/360 |
240/180 |
|
Max Spiral Start |
3 |
4 |
4 |
4 |
3 |
2 |
|
Max turn each start |
4 |
5 |
5 |
5 |
5 |
5 |
|
|
Feeding Particle Size (mm) |
4-0.04 |
0.8-0.037 |
0.3-0.03 |
0.3-0.03 |
0.2-0.02 |
0.2-0.02 |
|
|
Feeding Density (%) |
20-45 |
25-50 |
25-55 |
25-55 |
25-55 |
25-55 |
|
|
Capacity (t/h) |
15-40 |
6-8 |
4-6 |
2-3 |
0.8-1.2 |
0.1-0.2 |
|
|
Outline Size
|
L(mm) |
2300 |
1560 |
1360 |
1060 |
700 |
460 |
W(mm) |
2300 |
1560 |
1360 |
1060 |
700 |
460 |
|
H(mm) |
6500 |
5230 |
5230 |
4000 |
2600 |
1500 |
|
Weight (kg) |
900 |
800 |
600 |
400 |
150 |
50 |
|
