Help CenterSelf Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder/ Swinging Feeder/Trough Feeder/Chute Feeder
Related Products
-
Outstanding Quality Feeding Equipment /Trough Feeder/Feeding MachineUS$ 2,600 - 3,200MOQ: 1 Set -
Outstanding Quality Feeding Equipment/Swaying Feeder/Shaking Feeder/ Swinging Feeder/Trough Feeder/Chute Feeder/Vibratory FeedUS$ 2,600 - 3,200MOQ: 1 Set
-
Screw Feeder/Separator/ Separating Tank/Sized Feed/Spitzkasten/Spiral Classifier/Spiral Concentrator/Spiral SeparatorUS$ 111 - 5,555MOQ: 1 Set
-
High Quality Feeder Machine,Mining Vibrating Feeder Design,vibrating Hopper Feeder Machine/vibrator Bowl FeederUS$ 1,000 - 8,000MOQ: 1 Set
-
Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/Shaking FeederUS$ 1,250 - 4,500MOQ: 1 Set
Trough to the mining machine and the Pendulum feeder for mineral processing, coal, chemical industry and other sectors will be granular and massive materials sent out from the storage silos by a variety of different types of feed devices, but not suitable for conveying ore powder and other powder materials.
This machine can be used as ball mill and the mine belt conveyor continuous and uniform supply of granular material feed set
Model |
Unit | 400/300 | 600/500 | 980/1240 | 1000/1900 | 1060/2900 |
Feed size | mm | 50 | 205 | 300 | 300 | 350 |
Frequency bottom back and forth | r/min | 18.5 | 18.9 | 24 | 27 | 30 |
Crank Stroke | mm | 0-50 | 0-50 | 0-50 | 0-125 | 0-125 |
Capacity | t/h | 0-5 | 10-50 | 36-90 | 200-300 | 400-900 |
Power | kw | 3 | 4 | 7.5 | 11 | 25-40 |
Overall dimensions | mm | 2820/800/600 | 2700/900/850 | 3560/1000/1000 | 3900/1590/1350 | 4580/2950/1750 |
Weight | kg | 790 | 1050 | 1700 | 2690 | 3200 |
Model |
Unit | 300/300 | 400/400 | 600/600 |
Feed size | mm | 20 | 35 | 50 |
Oscillation Frequency | r/min | 68 | 47 | 45.5 |
Eccentric travel | mm | 0-90 | 0-170 | 0-206 |
Capacity | t/h | 8 | 12 | 25 |
Power | kw | 1.1 | 1.1 | 1.5 |
Overall dimensions | mm | 1130/920/850 | 1070/550/560 | 1320/820/740 |
Weight | kg | 210 | 250 | 5500 |
