Help CenterHigh Efficiency Feeder/Librating Feeder/Vibratory Feeder / Vibrofeeder
Related Products
-
Vibrating Feeder/Vibratory Feeder EquipmentUS$ 1 - 50,000MOQ: 1 Set -
High Efficiency Feeder From Oasis (manufacturer)US$ 100 - 55,555MOQ: 1 Set
-
Small Feeder From China Oasis FactorUS$ 100 - 55,555MOQ: 1 Set
-
Feeding MachineUS$ 1,562 - 45,680MOQ: 1 Set
-
Vibrating FeederUS$ 4,562 - 96,545MOQ: 1 Set
Specifications
1. a simple structure,2.high efficiency,
3. convenient operation,
4.easy maintenance
Technical Parameter of laboratory Feeder
Trough to the mining machine and the Pendulum feeder for mineral processing, coal, chemical industry and other sectors will be granular and massive materials sent out from the storage silos by a variety of different types of feed devices, but not suitable for conveying ore powder and other powder materials.
This machine can be used as ball mill and the mine belt conveyor continuous and uniform supply of granular material feed set
Model | Uite | 400/300 | 600/500 | 980/1240 | 1000/1900 | 1060/2900 |
Feed size | mm | 50 | 205 | 300 | 300 | 350 |
Frequency bottom back and forth | r/min | 18.5 | 18.9 | 24 | 27 | 30 |
Crank Stroke | mm | 0-50 | 0-50 | 0-50 | 0-125 | 0-125 |
Capacity | t/h | 0-5 | 10-50 | 36-90 | 200-300 | 400-900 |
Power | kw | 3 | 4 | 7.5 | 11 | 25-40 |
Overall dimensions | mm | 2820/800/600 | 2700/900/850 | 3560/1000/1000 | 3900/1590/1350 | 4580/2950/1750 |
Weighe | kg | 790 | 1050 | 1700 | 2690 | 3200 |
Model | Uite | 300/300 | 400/400 | 600/600 |
Feed size | mm | 20 | 35 | 50 |
Oscillation Frequency | r/min | 68 | 47 | 45.5 |
Eccentric travel | mm | 0-90 | 0-170 | 0-206 |
Capacity | t/h | 8 | 12 | 25 |
Power | kw | 1.1 | 1.1 | 1.5 |
Overall dimensions | mm | 1130/920/850 | 1070/550/560 | 1320/820/740 |
