XDF ModelΦ250×200 High voltage Electrostatic Separator is mainly applied for separation of conductor and non-conductor minerals and classification of planting materials instead of screening operation as well as food processing and seed selection.
serial number
| item | Number value | unit | ||
1 | Drum tube | φ 250 × 200 | mm | ||
2 | Drum drum rotational speed | 50 ~ 300 | r/min | ||
3 | corona electrode
| 0.2 | mm | ||
1 ~ 5 | |||||
4 | static level
| φ 30 | mm | ||
1 |
| ||||
5 | electrode control
| 50 | mm | ||
60 | |||||
6 | hairbrush | φ 105 × 60 | mm | ||
7 | Brush speed |
|
| ||
8 | Drum tube heating | temperature | 50 ~ 60 | °C | |
power | 900 | W | |||
9 | Silo heating | temperature | 100 ~ 300 | °C | |
power | 900 | W | |||
10 | Opening the gate silo calibration | 0 ~ 20 | mm | ||
11 | 0 ~ 30 |
| |||
12 | Adjustable |
| |||
13 | Processing material particle size | 0.04 ~ 1 | mm | ||
14 | handling ability
| 15 ~ 30 | Kg/h | ||
15 | High voltage power supply power | 800 | W | ||
16 | maximum voltage
| 60 | Kv | ||
17 | overall dimension
| 920×1120×1850 | mm | ||
18 | weight | 400 | Kg | ||
