Help Center2012 New Style Stone Jaw Crusher With CE Certificate
Related Products
PE,PEX jaw crusher
1 The best crusher for breaking stone.
2 Stone Crusher Form 50-1000t/h.
3 Stable performance.
4 ISO9001:200
This crusher is widely used in mining, metallurgical industry, building material, highway, railway, water conservancy and chemical industries. Various material with compressive resistance less than 350Mpa can be crushed.
This series of crusher features are: simple structure, reliable operation and maintenance easy, broken up more than 20-30, you can simplify the crushing process, save investment and production costs, the broken particle size more uniform, will not have been crushing the phenomenon .
PE jaw crusher main technical parameters
Model
| Technical performance | motor power(kw) | overall dimensions (LengthXwidthXhigh) (mm) | weight(t)
| |||
Max.Feed size (mm) | Output size (mm) | Theory processing capacity (M³/h) | Eccentric shaft speed (r/min) | ||||
PE150X250 | 125 | 10-40 | 0.6-3 | 300 | 5.5 | 875X745X935 | 1.1 |
PE250X400 | 210 | 20-60 | 3-13 | 300 | 15 | 1430X1310X1340 | 2.8 |
PE400X600 | 340 | 40-100 | 10-34 | 275 | 30 | 1700X1732X1655 | 6.5 |
PE400X600G | 340 | 40-100 | 12-38 | 275 | 30 | 1655X1732X1586 | 6.5 |
PE500X750 | 425 | 50-100 | 45-80 | 275 | 55 | 2030X1966X1920 | 11.9 |
PE600X900 | 500 | 65-160 | 60-150 | 250 | 75 | 2248X2180X2373 | 16.7 |
PE750X1060 | 630 | 80-140 | 100-220 | 250 | 110 | 2531X2370X2783 | 25.0 |
PE900X1200 | 750 | 95-165 | 150-280 | 218 | 132 | 3135X2966X3220 | 42.2 |
PE1100X1400 | 850 | 220±50 | 350-700 | 238 | 180 | 3114X2823X3320 | 49.6 |
PEZ1100X1400 | 850 | 220±50 | 350-700 | 238 | 180 | 3100X3177X3104 | 51.6 |
PE1200X1500 | 1020 | 150-300 | 400-800 | 180 | 220 | 3100X2799X3260 | 85 |
PEX jaw crusher main technical parameters
Model
| Technical performance | motor power (kw) | overall dimensions (LengthXwidthXhigh) (mm) | Weight (t)
| |||
Max.Feed size (mm) | Output size (mm) | Theory processing capacity (M³/h) | Eccentric shaft speed (r/min) | ||||
PEX-150X750 | 125 | 10-40 | 5-16 | 320 | 15 | 1380X1628X1025 | 3.5 |
PEX-350X750 | 300 | 15-50 | 16-35 | 300 | 30 | 1535X1880X1596 | 6.5 |
PEX-250X1000 | 210 | 15-50 | 10-32 | 330 | 37 | 1530X1992X1380 | 6.5 |
PEX-250X1200 | 210 | 15-50 | 25-43 | 330 | 37 | 1530X2192X1380 | 7.2 |
PEX-350X1300 | 250 | 20-90 | 20-85 | 300 | 75 | 2335X1800X1663 | 11.0 |
