Product Details
Condition: | New | Type: | Other | Place of Origin: | Jiangxi, China |
Brand Name: | oasis | Model Number: | BLL | Certification: | ISO9001:2008 |
Product Description
OASIS Company is the famous manufacturer of ball mill,since 2002,our ball mill has been exported more than 20 countries such asRussia,Chile,Vernezuela,Peru,Ukraine,SouthKorea,Yemen,Indonesia,Spain,Greece,India,and so on.
Introduction of Ball Mill
Ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc, it can grind various ores and other materials with dry type and wet type.
There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material.
Working Principle of Ball Mill:
The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
Model | Speed of bucket(r/min) | Weight of Ball(t) | Max.Feed Size(mm) | Output Size(mm) | Hourly Capacity(t/h) | Power(kw) |
Ø900x1800 | 37 | 1.8 | ≤15 | 0.075-0.89 | 0.5-2 | 15 |
Ø900x2100 | 37 | 2.3 | ≤15 | 0.075-0.89 | 0.65-2 | 18.5 |
Ø900x3000 | 35 | 3.85 | ≤25 | 0.075-0.89 | 1.1-2.5 | 22 |
Ø1200x2400 | 35 | 4.6 | ≤25 | 0.075-0.6 | 1.3-3.2 | 30 |
Ø1200x2800 | 35 | 5.4 | ≤25 | 0.074-0.6 | 1.5-3.7 | 37 |
Ø1200x4500 | 35 | 8.6 | ≤25 | 0.074-0.4 | 3.7-6.79 | 45 |
Ø1500x3000 | 29 | 9 | ≤25 | 0.047-0.4 | 3.3-8.2 | 75 |
Ø1500x3500 | 29 | 10.5 | ≤25 | 0.047-0.4 | 3.3-8.5 | 75 |
Ø1500x4500 | 29 | 13.5 | ≤25 | 0.047-0.4 | 4.5-12 | 90 |
Ø1500x5700 | 29 | 17 | ≤25 | 0.047-0.4 | 2.6-14 | 110 |
Ø1830x3000 | 24 | 13.5 | ≤25 | 0.047-0.4 | 4-15 | 135 |
Ø1830x3600 | 24 | 14 | ≤25 | 0.047-0.4 | 4-16 | 135 |
Ø1830x4500 | 24 | 20 | ≤25 | 0.047-0.4 | 4-19 | 155 |
Ø1830x7000 | 24 | 31.5 | ≤25 | 0.047-0.4 | 6-22 | 210 |
Ø2100x3000 | 22 | 18 | ≤25 | 0.047-0.4 | 6.4-28 | 210 |
Ø2100x3600 | 22 | 20 | ≤25 | 0.047-0.4 | 7-28 | 210 |
Ø2100x4000 | 22 | 21.5 | ≤25 | 0.047-0.4 | 7.6-28 | 210 |
Ø2200x3600 | 21.7 | 25 | ≤25 | 0.047-0.4 | 5.2-32 | 245 |
Ø2200x7000 | 21.7 | 46 | ≤25 | 0.047-0.4 | 15-38 | 380 |
Ø2400x3600 | 21 | 28 | ≤25 | 0.047-0.4 | 8-60 | 320 |
Ø2400x4500 | 21 | 35 | ≤25 | 0.047-0.4 | 8.5-60 | 380 |
Ø2400x7500 | 20.8 | 38 | ≤25 | 0.047-0.4 | 30-42 | 475 |
Ø2700x3600 | 20.7 | 40 | ≤25 | 0.047-0.4 | 12-80 | 400 |
Ø2700x4500 | 20.7 | 48 | ≤25 | 0.047-0.4 | 12-90 | 430 |
Ø3000x4500 | 20.7 | 55 | ≤25 | 0.047-0.4 | 50-105 | 580 |
Ø3000x9000 | 20.7 | 75 | ≤25 | 0.047-0.4 | 80-90 | 800 |
Ø3200x3600 | 18 | 55 | ≤25 | 0.047-0.4 | 60-120 | 630 |
