In the hammer crusher, the motor drives the rotor to rotate at a high speed through the belt, and on the rotor there are series of hammers. When the materials get into the working area of hammers, the rotating hammers with high rotation speed are crushing them, the crushed products meeting the required size can be discharged by the outlet and become the final products.
Technical Specifications
Model |
Rotor speed (r/min) |
Feed opening (mm) |
Max feeding size (mm) |
Discharging size (mm) |
Capacity (t/h) |
Motor power (kw) |
Weight (t) |
Overall dimensions L×W×H(mm) |
PC400×400 |
1500 |
145×450 |
100 |
0-30 |
5-8 |
7.5 |
0.9 |
844×942×878 |
PC600×400 |
1000 |
295×450 |
100 |
0-35 |
10-12 |
18.5 |
1.03 |
1054×972×1117 |
PC600×600 |
1000 |
295×570 |
100 |
0-35 |
12-18 |
45 |
2.14 |
1315×840×1501 |
PC800×600 |
1000 |
350×570 |
120 |
0-45 |
20-25 |
55 |
2.45 |
1515×2586×1040 |
PC800×800 |
1000 |
350×850 |
120 |
0-45 |
35-45 |
55 |
3.05 |
1515×2831×1040 |
PC1000×800 |
1000 |
580×850 |
200 |
0-45 |
25-40 |
110 |
6.5 |
3206×2210×1515 |
PC1000×1000 |
1000 |
580×1060 |
200 |
0-45 |
40-80 |
132 |
7.59 |
3514×2230×1515 |
PC1250×800 |
750 |
650×850 |
200 |
0-45 |
20-50 |
132 |
11.7 |
2630×1780×2050 |
PC1250×1250 |
750 |
650×1330 |
200 |
0-45 |
90-110 |
185 |
13.2 |
2630×2180×2050 |
PC1400×1400 |
750 |
1050×1540 |
250 |
0-45 |
120-170 |
280 |
17.2 |
2790×2800×2310 |
PC1600×1600 |
600 |
1500×1785 |
350 |
0-60 |
220-280 |
450 |
22.8 |
3350×3120×2660 |
