Waste Rubber Recycling Machine for Rubber Powder: XKP-560G
1. STRUCTURAL FEATURES:
The working surface of roll is made of FORGED STEEL with HARD ALLOY. Only the back roll is fluted. The surface is rigid and anti-wear. The internal cavity is processed to ensure a well-proportioned temperature on the roll face.
The machine is equipped with an overload protection device to prevent the major components from being damaged due to overloading.
The machine is also equipped with an emergency device. When an emergent accident happens, just draw the pull-rod, and the machine will stop immediately. It is safe and reliable.
The transmission system may adopt either a NGW planetary hardened-gear speed reducer or an inverted-Y speed reducer, both of which are compactly structured with features of low noise, high efficiency and a long service life.
The base of the machine is a complete framework or a combined framework of cast piece, which is convenient for installation.
2. APPLICATION:
The machine is applicable for breaking scrap rubber and virgin rubber.
3. MAIN SPECIFICATION:
Model |
XKP-450G |
XKP-560G |
|
Working Diameter of Front Roll |
450mm |
510mm |
|
Working Diameter of Back Roll |
450mm |
560mm |
|
Working Length of F. & B. Rolls |
800mm |
800mm |
|
1000 |
1000 |
||
Linear Speed of Front Roll |
23 meter/min |
22.3 meter/min |
|
Linear Speed Ratio of F. & B. Rolls |
1:1.94 |
1:1.96 |
|
Maximum Nip |
10mm |
15mm |
|
Main Motor Model |
Y280M-6 |
Y280M-6 |
|
Motor Power |
55 kw |
90 kw |
|
Motor Rotating Speed |
980rpm |
980rpm |
|
Speed Reducer |
NGW Planetary Hardened-gear Speed Reducer |
||
|
Overall Dimensions |
Length |
5000mm |
5500mm |
Width |
1900mm |
2330mm |
|
High |
1750mm |
1780mm |
|
Weight |
10700kgs |
20000kgs |
|
