BL380EK Sevro Saving Energy Plastic Injection Molding Machine
Feature Specifications
Machine Type | BL380EK | |||||
| International specification | UNIT | 2400/3800 | |||
Injection Unit | Screw diameter |
| A | B | C | D |
mm | 65 | 70 | 75 | 80 | ||
Screw ratio |
| 23 | 21 | 20 | 18.5 | |
Theoretical injection capacity | cm3 | 1211 | 1410 | 1615 | 1840 | |
Shot weight(PS) | g | 1115 | 1295 | 1485 | 1690 | |
oz | 39.3 | 45.6 | 52.3 | 59.5 | ||
|
|
| ||||
Injection rate | cm3/s | 355 | 412 | 473 | 538 | |
Injection pressure | Mpa | 197 | 170 | 148 | 130 | |
Injection stroke | mm | 365 | ||||
Max. Screw speed | r/min | 188 | ||||
Clamping Unit | Clamping force | Ton | 388 | |||
kN | 3800 | |||||
Opening stroke | mm | 750 | ||||
Space between tie bar | mm×mm | 760×710 | ||||
Min. mould height | mm | 300(255) | ||||
Max. mould height | mm | 750(705) | ||||
Max. distance Platen | mm | 1500(1455) | ||||
Ejector stroke | mm | 210 | ||||
Ejector force forward | kN | 113 | ||||
Ejector force back | kN | 75 | ||||
Number of ejector bar | PC | 13 | ||||
Electric Power | Sys. Pressure | MPa | 16 | |||
Pump Motor | kW | 51 | ||||
Heater power | kW | 26.25 | ||||
Number of temp. control zones |
| 4+1 | ||||
Others | Bucket capacity Oil tank capacity | kg L | 50 600 | |||
Machine dimensions(L×W×H) | m×m×m | 7.4×1.76×2.3 | ||||
Machine weight | Ton | 14.5 | ||||
