HF-98A Auto Vaccum Forming & Packing Machine

HF-98A Auto Vaccum Forming & Packing Machine

HF-98A Auto Forming & Packing Machine series utilize tensility to thermoforming container by thermoplastic soft or hard film, and vacuum sealing after filling, vacuuming, sealing and cutting together to improve efficiency by low energy consumption. The packaging areas mainly focus on foodstuff, one-off iatrical produce, commodity and etc.

Features
1. Easy clean and sanitary by stainless steel construction.
2. BUSCH vacuum pump from Germany guarantee performance and durability.
3. Digital display PLC interface with touching panel from Japan for easy operation.
4. Various wrapper and specification choice with scope on the same machine.
5. Servo diver from Japan makes circulate placidly and accurately.
6. Versality in running many different formats and sizes on same machine only need to change mould.

Technical Data:
Packing Capacity:             5-7cycles/min
Bottom film thickness:        ≤0.8mm
Bottom film width:              322, 422, 522mm
Top film width:                    300, 400, 500mm
Max. forming area:              ≤500x400mm
Max. forming depth:            80mm
Power Supply:                    3 PH/ AC380V/50HZ
Air Consumption:                500-650L/min
Dimension(mm):                  4500x1000x1760(LxWxH)
Weight:                               approx1300kg
Air Supply:                           ≥0.6Mpa
Loading Length:                    ≥1.5m
Power:                                            10kw

Optional Functions:
1. Printing Function: Printout single or multiple lines with production date, numbers of code and batch
2. Cleaning Function: Provide CIP washing system
3. Conveyor: Linear conveyor transport output automatically

About Our Company:

Dalian Mach Co., Ltd. specializes in exporting all kinds of machinery such as Metal Processing Machines, Paper Processing Machines, Packaging Machines, Rubber Machinery, Pharmaceutical Machines, Daily Product Making Machines and Forklifts. With more than twenty years' experience, our professional team will provide best service for you.

We have a group of professional engineers in charge of technology, manufacturing, installing and testing, so we can guarantee that our machines will put on good performance based on high quality.

Our products have been exported to more than 60 countries such as Canada, the U.S.A., Italy, France, Guatemala, Brazil, Bolivia, Chile, Russia, Romania, Saudi Arabia, Syria, Jordan, the U.A.E., Indonesia, Singapore, Thailand, India, Pakistan, South Africa, Egypt, Nigeria, Kenya and Ghana.

We sincerely hope to establish a long-term cooperative relationship with you and become your true partner when you need our service

...
