1.
2 Automatic dumpling wrapper forming machine
| Model | Dumpling wrapper making machine |
Pastry width |
220mm |
Working capacity/min |
180-200pcs |
| Power | 3.0kw |
| Net weight | 230kg |
| Outer size | 1400*650*1200mm |
1.Diameter:60mm, interior thickness: 2.0mm, side thickness: 1.5mm, net weight: 6.5g
2.Diameter: 68-70mm, interior thickness: 2.0mm, side thickness: 1.2mm, net weight: 8.3-8.5g
3.Diameter: 73-75mm, interior thickness: 2.0mm, side thickness: 1.0mm, net weight: 8.3-8.5g
4.Diameter: 80-83mm, interior thickness: 1.6mm, side thickness: 0.8mm, net weight: 9.2-9.5g
5.Diameter: 93-95mm, interior thickness: 1.6mm, side thickness: 0.96mm, net weight: 9.5-10.0g
6.Diameeter: 97mm, interior thickness: 3.5mm, side thickness: 1.8mm, net weight: 22+0.5g
7.Ellipse length: 72mm, width: 57mm, interior thickness: 1.5mm, side thickness: 1.0mm, net weight: 7.0g
8.Ellipse length: 80mm, width: 60mm, interior thickness: 2.3mm, side thickness: 1.5mm, net weight: 9.0g
9.Ellipse length: 80mm, width: 70mm, interior thickness: 2.0mm, side thickness: 1.0mm, net weight: 9.0-10.0g
Machine’s Advantages:
Roller arrangement, chain and chain wheel transmission, with convenient maintenance.
Automatic feeding, automatic forming and automatic return.
-
Roll drawing, uniform feeding, panel neat, save more labor. It can be customized according to users’ need. It can save labor, improve work efficiency greatly.
Description of the machine:
It can produce various specification of dumpling skins, wanton skins, spring roll skins and so on, suitable for small and large wholesalers of dumpling wrappers, wonton wrappers, spring roll wrappers. No offcut left, no need another equipment, it’s very convenient for using.
Working principle:
Put paste into the hopper, dumpling paste comes out through the conveyor belt after press by three channel rollers. Flour is put on dumpling paste by the flour box, then the dumpling paste is forming through the mould roller. The dumpling wrapper will be overlaid automatic, the leftover will be be transferred into the hopper by the conveyor belt
