1. Pictures of Compression Testing Machine
2. Description of Compression Testing Machine
This product is suitable for compression test of materials such as concretes, cements & cement products, various building blocks, hollow bricks as well as ordinary baked bricks, which is also appropriate for compression, flexural and bending tests of other metallic, non-metallic materials and products. The machine features high precision, stable and reliable performance, reasonable structure, manually adjustable screw lift, arbitrarily adjustable test space, convenient and labor-saving operation and high working efficiency, various grip accessories can be configured according to user needs for multi-use purpose.
Specification
Model |
TSY-2000 |
Maximum test force (kN) |
2000 |
Effective measurement range (kN) |
0-2000 |
Relative error value |
±1% |
Distance between upper and lower platen (mm) |
320 |
Bearing plate diameter (mm) |
320*260 |
Piston stroke (mm) |
40 |
Piston diameter (mm) |
Φ250 |
Hydraulic pump rated pressure (MPa) |
40 |
Power(kW) |
0.75 |
Voltage |
AC380V/220V±10% 50Hz |
Overall dimensions (mm) |
1000*440*1200 |
Net weight (kg) |
800 |
Gross weight (kg) |
950 |
