1. Pictures of WAW Model 1000KN Computerized UTM Electronic Universal Tensile Strength Testing Machine Manufacturer
2. Description of WAW Model 1000KN Computerized UTM Electronic Universal Tensile Strength Testing Machine Manufacturer
Universal Machine is suitable for testing tensile,compression,bending,shear,peel,tear and other mechanical properties of metallic,non-metallic and composite materials and materials and components.Universal machine adopts underneath type cylinder,microcomputer control and electro-hydraulic servo,and has the advantages of high precision,simple and convenient operation,and large data storage capacity.
Specification
| Model | WAW-100B | WAW-300B | WAW-600B | WAW-1000B |
| Maximum Test Force(kN) | 100 | 300 | 600 | 1000 |
| Effective Measurement Range(kN) | 0-100 | 0-300 | 0-600 | 0-1000 |
| Relative Error Value | ±1% | |||
| Maximum Tensile Test Space(mm) | ≥480 | ≥690 | ||
| Maximum Compression Test Space(mm) | ≥480 | ≥620 | ||
| Flat Specimen Clamping Thickness(mm) | 0-15 | 0-30 | ||
| Circular Specimen Clamping Thickness(mm) | 10-20 | 10-32 | 13-40 | |
| Piston Stroke(mm) | 150 | |||
| Size Of Upper And Lower Platen(mm) | Φ176* Φ176 | Φ180* Φ180 | Φ220* Φ230 | |
| Bending Test Roller Spacing(mm) | 100~450 | 100~500 | ||
| Tension And Compression Space Between Pillar | ≥450 | ≥570 | ||
| Maximum Rising Speed Of Counter(mm/min) | ≥100 | |||
| Maximum Lifting Speed Of Moving Beam(mm/min) | ≥240 | |||
| Motor Power(kw) | 1.5 | 2.1 | ||
| Working Noise(dB) | ≤75 | |||
| Voltage | AC380V±10% 50HZ | |||
| Main Machine Overall Dimensions(mm) | 770*520*1850 | 800*500*1850 | 950*230*2060 | 950*230*2060 |
| Load Ark Overall Dimensions(mm) | 1200*610*830 | 1200*610*830 | ||
| Net Weight(Kg) | 1600 | 2400 | ||
| Gross Weight(Kg) | 1800 | 2600 | ||
3.More Products To Choose
|
|
|
|
|
Fluidized Freezer |
Spiral Freezer |
Plate Freezer |
Tunnel Freezer |
5.Why Choose Us
1.Product development and special customized ability for clients.
2.The independent intellectual property rights and the international certification authority.
3.High quality material - product quality exceed international counterparts.
1.Trade Items Of Products
| Payment | L/C,T/T,and etc. |
| Port | Shanghai or Ningbo |
| MOQ | 1 Set |
| Supply Ability | 2Twenty-Foot Container/Week |
| Delivery | 30-45 working days at appointed port |
2.Packaging Of Products
Introduction Of Company
Shangyu Kanglong Refrigeration And Fanner Equipment Co.Ltd.:
1.Entered the filed of food freezing industry more than 15 years.
2.Fast delivery, 30 Working days / 40' feet container.
3.Product are exported to more than 20 countries.
4.15 years experience, 10500mm2 ISO9001 certified workshop.
5.Precision equipment are mainly sourced from Germany, Janpan, Taiwan, Korea.
6.High quality material, was sourced from famous brand in China.
7.Main Products:
IQF Freezer,Food Treatment Production Line,Food Processing Machine,Food Drying Equipment,Refrigeration Equipment
