High pressure shisha charcoal tablet briquette machine/hookah charcoal punch press

Specifications

shisha charcoal tablet briquette press machine
1. High quality and hardness
2. Automatic
3. Professional technology

High pressure shisha charcoal tablet briquette machine/hookah charcoal punch press





Introduction of shisha charcoal tablet briquette press machine:



Our shisha charcoal tablet briquette press machine, which is mainly used for making the shisha charcoal tablets, belongs to single-pressure-type single punch shisha charcoal tablet briquette press machine, can press all kinds of charcoal powdery material into various kinds of special briquettes like circular slice, square, etc. The shapes and size of the shisha charcoal tablet briquette press machine tablet is adjustable, and different size, strength and hardness of charcoal piece can be made according to customers' requirement.

Our shisha charcoal tablet briquette press machine can press 45 times per minute, which could reach to 30 thousands pieces of briquettes. The outlet tablet shape can be round tablet, cubic, cone, rhomboid, triangular, cylinder, scrotiform, convexity, concavity and also you can press word, logo, pattern, etc.





Merits of shisha charcoal tablet briquette press machine:



(1). The shisha charcoal tablet briquette press machine suitable for the production of large diameter, the filling amount of tablets.

(2). The particular design of the forced feeding device, can suppress dry and wet many kinds of materials.

(3). The shisha charcoal tablet briquette press machine with specially designed auxiliary equipment, can realize the automatic feed, automatically sends finished products.

(4). User-friendly design, make the pressing machine easy to clean and maintenance.

(5). The noise is low, resistance to wear.

(6). We have more than 30 kinds of binder formular providing.





Notice of using shisha charcoal tablet briquette press machine:



1. This machine should be started under no-load condition, started with material is forbidden.

2. Strictly prohibit that material without iron into the machine, so as not to break the moulds.

3. Before starting the gear part should be redictors oil.

4. The chain and sprocket wipe redictors oil every 7 days.

5. Bearing seat redictors of oil once every three months.

6. The reducer must add gear oil before started, every four months changing gear oil once.





Material of shisha charcoal tablet briquette press machine:



1. Applicable raw material: charcoal powder of biomass material such as: sawdust, wood shavings, wood wastes, branches, rice husk, peanut shell, coconut shell, begasse, sediment, cotton stem, corn stalk, corn cob, etc. After carbonization, the charcoal can be used as raw material.

2. The inlet particle size of raw material: it must be less than 2mm.

3. You must add a certain proportion of liquid binder of some kinds of materials for shaping easily, besides, the binder can also increase the hardness of material, and make the briquettes easily burning.

4. The moisture of materials for briquetting must be moderate, the water content should be 12-15%.



Shisha charcoal tablets:



This kinds of shisha charcoal tablet briquette press machine also can suitable in pharmacy, foodstuff, coal, chemical engineering, metallurgy building materials, refractory, etc, industry.

1) Size and shapes: Size: round: 20-45mm, square: 15-55mm Shape: round, square, restabgle, triangle, cylinder, diamound, cone, etc you can also put words, logo, like brand, etc, on the tablets.

2) Characteristics: The shisha charcoal tablet briquette press machine use the quick burning charcoal technology, the tablet can burn from the top to down. Firepower fierce, smokeless, tasteless, non-toxic, long burning time.





How to make high quality shisha charcoal tablets?



1. Firstly, you must have good hard charcoal materials: The raw material requirements as the above shows.

2. Secondly: you have to use the good shisha charcoal tablet briquette press machine: here in our factory, we mechanical and hydraulic two types shisha charcoal tablet briquette press machine.

3. Thirdly: you need the good binder formula: here in our factory, we have more than 30 kinds of Binder Recipes providing, our factory has been a professional manufacturer in this field since 1980s, can according to your different quality of charcoal materials to provide the most suitable recipe, help you make high quality shisha charcoal tablets. Besides, our binder is strong viscour, non-toxic and easily got from your markets.

4. Evaluating of good quality shisha charcoal tablet briquettes: 1) Easy to fire and with long burning time. 2) Smokeless and good smell when burning.





Hydraulic type shisha charcoal tablet briquette press machine:



Our hydraulic type shisha charcoal tablet briquette press machine newly designed by our technicist and workers based on the mechanical type of shisha charcoal tablet briquette press machine. This machine with an operation table, by which you can directly operate the machine to produce shisha charcoal tablets, or set the working method for the machine to work automaticlly. Besides, there are also an oil pump, by which the pressure are highly increased for pressing the charcoal powder into tablets. And the oil in the pump just for producing pressure, but no consupmtion, so this machine is also energy saving equipment. Strong and perfect structure design, make it suitable for any kinds working conditions, and with good working performance.







Parameters of shisha charcoal tablet briquette press machine:



Model	LTM-9	LTM-12
Power	7.5 kw	15 kw
Capacity	150--200 kg/h	200--300 kg/h
Pressure	80 t	120 t
Feeding Material	≤ 3mm	≤ 3mm
Tablets Size	20-45 (round), 15-55 (cubic)	20-45 (round), 15-55 (cubic)
Pressure Type	mechanical pressure	hydraulic pressure
Weight	1350 kg	1500 kg

How to do the payment, packaging and delivery?



1. Payment:

30% down payment by TT in advance, or pay directly by Crush, 70% TT balance pay off before delivery.

2. Packaging:

1). All the machines will be wrapped up with plastic film firstly (including the motors)

2). The plastic film bag wrapped machine, according to the size and weight to make wooden or iron box, put machine in and fixed the box after loading. (The box material can be made as your requirements)
3). The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.

3. Delivery:

After receive your down payment, we will prepare and manufacture all the machines for you, within 15-20 days, all will be finiahsed, we will send pictures to show you, after receive your balance, all the machines will be loaded on board and delivered to you.



< We promise: >



♥ Before Service:

1. According to our customers special requirements, provide the most suitable project design, process design and the purchase program.

2. Guide customers to choose the best and economical plant, recover investment within short time, and site inspection.

♥ On sale service:

1. Accompany you to check the working conditions of our machines.

2. Inspect the quality of all our machines.

3. Manufacturer the equipments as the contact appears at first time after receive your deposit. Arrange the delivery timely.

♥ After sale service:

1. Send engineers to your site, help you to install and debugging devides, build plant, and training operators, at the same time pass the technology on clay brick production to customers.

2. Guarantee of the equipments quality, maintenance, etc. Solve all the troubles for you timely during your production when receive your call oure-mails.
