Help CenterFactory Direct Sale Hookah Charcoal Pressing Machine
Related Products
-
Latest Design High Output Shisha Charcoal Tablet Briquette Forming MachineUS$ 5,000 - 10,000MOQ: 1 Set -
Shisha Hookah Charcoal Pressing Briquette Machine/coal Tablet Press MachineUS$ 6,000 - 10,000MOQ: 1 Set
-
High Pressure and Capacity Shisha Charcoal Tablet Press Machine for SaleUS$ 5,000 - 10,000MOQ: 1 Set
-
Latest Design Carbon Powder Tablet Press Machine/charcoal Briquette Press MachineUS$ 5,000 - 10,000MOQ: 1 Set
-
High Pressure Shisha Charcoal Tablet Briquette Machine/hookah Charcoal Punch PressUS$ 5,000 - 10,000MOQ: 1 Set
Specifications
hookah charcoal pressing machine1. 30 years experience
2. Best quality and thoughtful service
3. CE, ISO certificate
Factory direct sale hookah charcoal pressing machine
Brief introduction of the factory direct sale hookah charcoal pressing machine
The machine can press many different kinds of chips/tablets (circle, square, irregular, etc) by replacement of some spare parts.
The machine can press dry powder into circle chips/tablets, square, rectangle, ring, taper and so on by changing moulds.
The finished products’ surface is smooth and its pressure as well as density can be adjusted.
Pictures about the main parts of the hookah charcoal pressing machine
the material of part is chromium steel, the feature is high hardness, wear-resistant, corrosion-resistant and not rust, the service time is 3-4 years( 6-8 hours working time per day),
the mold use wire cutting process technology, so the size of mold is very precise. if the mold is abrasion, we can provide the mold with low price and high quality,
the mold is easy to repair and install.
Main features of the hookah charcoal pressing machine
1)Special design is suitable for light powder materials.
2)Reasonable structure with easy clearance and maintenance.
3)Transmission system in main gear box below airtight is completely separated, reducing noise and wear.
4)The model of hookah charcoal pressing machine is changeable.different model meet different requirements.
Two types of hookah charcoal pressing machine:
One Mechanical press type, the other is Hydraulica press type
the first type: Mechanical press hookah charcoal pressing machine: (11-16 pieces per time, 20-40 times per minture)
The second type: Hydraulic press type hookah charcoal pressing machine ( 36-48 pieces per time, 8-20 times per minture)
Include four parts:1) electric control cabinet, 2)touch screen, 3)hydraulic cyclinder,4) main engine.
The final products of hookah charcoal pressing machine:
1.The outlet shisha charcoal are good looking, smokeless, non toxic, long buning, one piece can burning more than one hour, easy fire and high heat.
2. we can provide the special binder formula after the order for free.
3. change the mould can be different shape, we can customize the mould as your requirements.
The whole production line related to hookah charcoal pressing machine
Raw materials----carbonization furnace----charcoal crusher----binder mixer----wheel mill----
shisha charcoal machine----finished shisha charcoal briquettes----dryer
If want to make good shisha hookah briquettes, must need to make attention on following:
1. Raw material: hardwood charcoal, coconut shell charcoal, bamboo charcoal are good material for make shisha briquettes.
2. only good quality hookah charcoal pressing machine can make good shisha hookah briquettes,our machine are patented products,
we have hydraulic type and mechanical press type for you choose.
3.It need to confirm the binder furmola is natural, smelless, nontoxic.we can provide the special binder foumula after order for free.
4.also we can depend on your specific situation design the production line to you.
Technical parameters of the hookah charcoal pressing machine
Model |
LTYJ-9 |
LTYJ-48 |
Applicable materials |
Charcoal powder, coal powder, sawdust, any powder material |
|
Capacity |
11-16 pieces/time 20-40 times/min |
48 pieces per time(30mm) 8-20 times/min |
Motor |
7.5 kw ( 4 pole) |
18.5 kw (4 pole_ |
Diameter of briquettes |
20, 25,30, 35, 38, 40, 43mm( round): 20-40mm( cubic) |
20, 25,30, 35, 38, 40, 43mm( round): 20-40mm( cubic) |
Feeding materials |
≤3mm |
≤3mm |
Briquette shape |
Round shape and cubic shape or as customers’ request |
Round shape and cubic shape as customers’ request |
Pressure |
40-60tons (adjustable) |
40-150tons |
Pressure type |
Mechanical press |
Hydraulic press |
Overall size |
2500*950*1550mm (include conveyor) |
3500*2000*1800mm (include conveyor) |
Packing size |
1500*1200*1750mm |
2100*2100*1900mm |
Weight |
1500kg |
5500kg |
Pre-sale service:
1.According to the customer needs to recommend relative models machine.
2.According to the customer's special requirements to customize equipments.
3.Our engineers will supply the site and equipment drawing.
After-sale service:
1.According to the purchase contract,our company can send engineers to help installation.
2.The quality guarantee is 1 year,not including the wearing parts.
3.Collecting customer feedback,solve the real problems faced by customers.
4.Our company supply sapre parts the whole year.
1. All the machines will be wrapped up with plastic film first (including the motor).
2. The plastic film bag wrapped machine, according to the size and weight to make wooden or iron box, put machine in and fixed the box after loading. (The box material can be made as your requirements)
3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
Our working experience about the hookah charcoal pressing machine
Lantian Mechanical Plant, which located in Gongyi, Henan province,is a modern enterprisewhich setsthe scientific research,
production and sales as a whole.We have a modern management system,the first-class processing art, perfect detection means, high quality science and technology talent team
and after-service system. Our company has been rated as "Quality Trustworthy Unit" "Brand-name
and High-quality products" and "QualityManagement Advanced Unit".In order to meet the different
requirements of customers, we designed and researched many types of charcoal processing
machine including charcoal & coal briquette machine, Shisha/hookah charcoal machine,sawdust
charcoal briquette machine, tablet press machine, rotary dryer vertical dryer, belt mesh dryer
and mixer, crusher, blinder, etc.
Other assistant equipments of the hookah charcoal pressing machine
1)crusher
the first step of factory direct sale hookah charcoal pressing machine is to crush raw material into fine hookah powder. The smaller the hookah powder's size is, the better.(hookah charcoal pressing machine)
2) whell mixer
The second step of the hookah charcoal pressing machine is to mix charcoal powder with natural binder evenly. The reason why we use wheel mixer is that wheel mixer can not only improve shisha powder's density, but also press shisha powder into smaller size. (hookah charcoal pressing machine)
3) Box dryer:
The last step of the hookah charcoal pressing machine is to dry shisha briquettes in box dryer. Due to the liquid binder, shisha charcoal will have 15-20% water content, so we need to dry the briquettes to 3-5%( hookah charcoal pressing machine)
Welcome to our factory to check performance of the hookah charcoal pressing machine or contact with me at any moment.
