charcoal press machine production line
Brief introduction of charcoal press machine production line
Endge Runner
Edge runners have many advantages. First of all, crushing cavity depth without dead zone so as to
improve the ability to feed and production.In addition ,It broke thoughtly and granularity. Second,
gasket type feeding mouthis adjusting ,convenient and reliable.Third, lubrication system increase
the flecibility of the equitments.What is more,it has small maintenance workloadand low operating
costs.Single machine saves 15 percent energy .Discharging mouth has adjusting ranges so as
to meet different customers, little noise and dust .Besides ,it can bear great impact load with
Hydraulic safely device.
charcoal press machine
charcoal press machine was used to press the carbon powder into wood pieces of
hookah. It belongs to advanced machine internationally at present. With 30 years
experience, our company possess rich technology formula and enjoy a good reputation.
Cube charcoal machine produced by lantian was suitable for hookah charcoal piece of
15 to 50 millimeters in diameter. Theses products were in wafer shape, one side
convex one side concave and generally in the 30 mm and 40 mm in diameter. In
addition, the thickness is about 23 mm. What is more, this equitment possess various
advantages such as smoothy surface, adjusted pressure, stable stamping and excellent
performence. Therefore, this machine in lantian is the best choice in hookah charcoal
industry.
Transportain Equitment
Characteristics of charcoal press mahcine:
1. This machine especially is suitable for the suppression of tablets with big diameters.
2. This machine could feed and produce automaticaly with special auxiliary equipment
3.Transmission system is completely separated by seal turbine box at the bottom of
the main body, ruducing noise and pollution.
4. This machine can compress carbon power with light weight and small density by forced feeder.
Technical Parameters:
| Model | LTM-9 | LTM-12 |
| Power | 7.5 kw | 15 kw |
| Capacity | 150--200 kg/h | 200--300 kg/h |
| Pressure | 80 t | 120 t |
| Feeding Material | ≤ 3mm | ≤ 3mm |
| Tablets Size | 20-45 (round), 15-55 (cubic) | 20-45 (round), 15-55 (cubic) |
| Pressure Type | mechanical pressure | hydraulic pressure |
| Weight | 1350 kg | 1500 kg |
Welcome to join us
Gongyi Lantian Machanical Plant
Mobile:0086--18738127720
QQ:2986744966
