Low cost hydraulic pressure sunflower seed oil press machine
When operating, the good processed oil material into the pressing chamber fom hopper, and the screw rotate to push-in the material for squeezeing. For the material is conducted in the motion state, under high pressure of chamber, the material, screw, and chamber have a great friction resistance, which resulting in relative motion.
On the other hand, due to te screw diameter is grudually thickening, the screw pitch is gradually declining, so when the screw rotating, the thread can move the embryo forward, also an flip them outward, at the same time the material close to the screw can rotate with the thread. So every embryo is with different speed and direction moving, with the moving between embryo, all the friction generate heat satisfy the needs of oil process operation,
helps to denaturation embryo protein, destorys the colloid, increases the plasticity, also reduces the viscosity and easy to precipitate oil. Thus increasing the yield efficiency.
The first production process: raw material-----frying-----pressing-----filtering-----pure oil
The second production process: raw materials-----crushing-----steaming-----pressing----
filtering-----pure oil
4. Different types and parameter information
Parameters |
LT-80 |
LT-100 |
LT-125 |
|
Screw diameter |
Φ80mm |
Φ100mm |
Φ123mm |
|
Screw speed |
35r/min |
37r/min |
40r/min |
|
Screw inner diameter |
Φ82mm |
Φ102mm |
Φ125mm |
|
Power |
Main machine |
Y-132-M2-6 |
Y132S-4 5.5KW |
15KW |
|
Vacuum pump |
Y801-4 |
Y802-4 |
1.5KW |
|
Heater |
2.2KW |
2.2KW |
4.2KW |
Raw material |
80-100kg/h |
150-200kg/h |
250-350kg/h |
|
Machine weight |
780 kg |
1100 kg |
1500 kg |
|
Dimension |
1600x1100x1550mm |
1800x1100x1550mm |
2200x1580x2100 mm |
|
Outstanding features of sunflower seed oil press machine:
1. High yield efficiency--comparing with original oil press machine, the normal yield efficiency higher of 4-6%. One hundred catties peanut will produce 4-6 catties more oil than before, so annual economic benefit is very considerable.
2. Energy saving--will reduce electric power of 40% of te same output, if it saves 6kw an hour, then 30 yuan electricity fee saved for a day's production.
3. Labor saving--will reduce labor force for 60% of same production, 1-2 people is can organize, which saves labor cost for 40 yuan.
4. Broad-spectrum--one machine can serve seceral purposes, more than 20 kinds of oil crops cam be squeezed by it, such as soybean, peanut, sesae, rapeseed, sunflower seed, til seed, etc. 3 levels squeezing, once completely squeeze all oil out.
5. Oily pure--vacuum filtering residue, ensure the purity of oil, conform to the health and quarantine standards.
6. Small area covering--oil mill needs only 10-20 square meter can satisfy the production.
