Home > Products > Oil Press > Small spiral oil press machine for Camellia oleifera seed from Lantian
Small spiral oil press machine for Camellia oleifera seed from Lantian
- 66 Set / Sets per Month
- Shanghai Qingdao etc
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | Lantian |
Model Number: | LT | Voltage: | 380V, 380v | Power(W): | 11kw |
Weight: | 1500kg | Dimension(L*W*H): | depend on the types | Certification: | CE ISO |
Warranty: | 12 Months, 112 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Small spiral oil press machine for Camellia oleifera seed from Lantian
Features:
1. Simple,convenient,energy saving,competitive price.
2.This oil press machine is composed of feeder, gearbox, pressing cage, screw shaft and machine stand etc
3.Final oil is high quality, good smell, and high yield rate.
4.It uses high carbon steel, which through high frequency quenching and heat-resisting, it is high hardness and strength, good abrasion resistance
5.That suit for high temperature and high pressure continous working, all this had improved the service life of the oil press for decades.
Advantages:
1. Make oil from seeds and nuts. Oil is for cooking and residue cake is for animal feed or fertilizer.
2. High working efficiency! Oil press of spiral type just need process the oil plants by one time to get the maximum oil.
3. Make high quality healthy oil! Mechanical squeezing craft does not harm the nutrients in the oil. No chemical substances left.
4. CostEffective! Just need replace the wearing parts. The main machine can run for more than 10 years.
the
1. Transferred by the triangle belt, the electromotor drives the spiral shaft.
2. The oil plants falls into the first section of the spirals through the feeding part and being carried toward the
end of the machine along with the rotating squeeze spirals.
3. As the space between the squeeze spirals are getting smaller, the oil plants frictions with each other as well as the
squeeze spirals and the squeeze loops. The pressure in the chest is becoming bigger.
4.During this process, the oil plants are smashed and big amount of heat is generated, the tissue cells are destroyed and the oil is
separated from the oil plants and flow out from several outlets.
5. After extracted, the oil plants turns to be cake containing low oil and discharged in thin slices from the end of the machine. The whole
oil and residue separation process is completed.
Parameters | LT-80 | LT-100 | LT-125 | |
Screw diameter | Φ80mm | Φ100mm | Φ123mm | |
Screw speed | 35r/min | 37r/min | 40r/min | |
Screw inner diameter | Φ82mm | Φ102mm | Φ125mm | |
Power | Main machine | Y-132-M2-6 | Y132S-4 5.5KW | 15KW |
| Vacuum pump | Y801-4 | Y802-4 | 1.5KW |
| Heater | 2.2KW | 2.2KW | 4.2KW |
Raw material | 80-100kg/h | 150-200kg/h | 250-350kg/h | |
Machine weight | 780 kg | 1100 kg | 1500 kg | |
Dimension | 1600x1100x1550mm | 1800x1100x1550mm | 2200x1580x2100 mm |
Pre-sales service: According to your raw material and capacity demand, we suggest suitbale machine for you,or a single main machine, several machines, or complete production line.
After-sales service: We can offer you related technical support and guide you to build up factory, install the machines, or dispatch our engineer to your factory for the installation.
Also we provide one year warranty for all of our products.
