hookah charcoal tablet press making machine
Character
This coconut shell charcoal making machine is applicable for making small round tablets or cubic shape from charcoal dust. The output coconut shell charcoal briquettes are with high density, perfect even shape, good appearance. Meanwhile, it is easy for ignition, no smell and last longer when burning.
Feature
1. Charcoal powder briquette machine is applied to suppress tablets with large volume from charcoal dust.
2. Special design is suitable for light powder materials.
3. Humanization design with easy clearance and maintenance.
4. Transmit system in main gear box below airtight is completely separated, reducing noise and wear.
Technical specifications
Model: YPJ9
The number of trimming die: 9
Nominal Force (kN): 120
Diameter of finished products (mm): 33 35 38 40 43
Capacity: 24Times/Min, 9Piece/Time
Overall dimension: 2500*900*1500
Motor Power (kW): 7.5
Equipment weight (Kg): 1500
|
Model (unit) |
Power (kw) |
Capacity (kg/hr) |
Tablet Diameter (mm) |
Briquette diameter (mm) |
Max feeding size (mm) |
Press Force (Kn) |
Weight (KG) |
JYP-9 |
7.5 |
40pcs/min,9pcs/time |
15-50 |
Less than 50 |
3 |
150 |
1350 |
JYP-12 |
7.5 |
40pcs/min,12pcs/time |
15-50 |
Less than 50 |
3 |
250 |
1850 |
Producton line
Charcoal block-----crusher-----mixer-----charcoal briquette press-----dryer-----final product (Shisha charcoal).
Gongyi Lantian Machanical Plant has 29 years experience for Briquetting and Pelletizing solution. Sincerely hope to be your business partner.
1) The single hookah charcoal tablet press machine will be packaged by wooden case with steel frame.
2) If the machines are lot, we will load the machines in the container with or without package which is based on your requirement.
3) All the machines will be adjusted and tested before shipping.
